6. Lower right cover
Open this cover when a paper jam occurs.
7. Right cover
Open this cover when a paper jam occurs.
Rear and left view
DLV004
1
1
1
1. Vents
Prevent overheating.
Guide to Components (mainly Asia)
• Do not obstruct the machine's vents. Doing so risks fire caused by overheated internal
components.
2. Getting Started
30
