Ricoh SP 6430DN Quick Installation Guide

Guía de Instalación RápidaQuick Installation
Verkorte Installatiehandleiding
Kurzanleitung zur Installation
Guia de Instalação Rápida
Guide d’installation rapide
Guia de Instalação Rápida
Guida di installazione rapida
Краткое руководство по установке
Test Printing
Testdruck
Impression test
Stampa di prova
Impresión de prueba
Testafdruk maken
Impressão de teste
Impressão de teste
Тестоваяпечать
CYN042
Select [List/Test Print] Press [OK]
[Liste/Testdruck] wählen
Drücken Sie [OK]
Sélectionnez [Impr. liste/test]
Appuyez sur [OK]
Selezionare [Stampa lista/prova]
Premere [OK]
Seleccione [Impr. lista/prueba]
Pulse [OK]
Selecteer [Lijst-/proefafd]
Druk op [OK]
Seleccione [Impr listas/teste]
Prima [OK]
Selecione [Lista/Impressão
de teste]
Pressione [OK]
Выберите[Печ.списка/тест]
Нажмите[OK]
Select[Cong.Page] Press [OK]
[Kongurationsseite]wählen
Drücken Sie [OK]
Sélectionnez [Page de confi
-
guration]
Appuyez sur [OK]
Selezionare [Pagina configu-
razione]
Premere [OK]
Seleccione [Página de congu-
ración]
Pulse [OK]
Selecteer[Conguratiepagina]
Druk op [OK]
Seleccione [Folha de configu
-
ração]
Prima [OK]
Selecione[Págcong]
Pressione [OK]
Выберите[СтраницаКонфиг.]
Нажмите[OK]
Installing the Printer
Driver
Installation des
Druckertreibers
Installation du pilote
d’impression
Installare il driver della
stampante
Instalación del driver
de impresora
Het printerstuur-
programma installeren
Instalar o driver de
Impressão
Instalar o driver de
impressão
Установкадрайвера
принтера
• For details about installing the printer driver,
see Driver Installation Guide on the “Printer
Drivers and Manuals” CD-ROM.
• Einzelheiten zur Installation des Druckertreibers
ndenSieinderTreiber-Installationsanleitung
auf der CD-ROM „Printer Drivers and
Manuals“.
• Pour plus d’informations sur l’installation
du pilote d’impression, consultez le Manuel
d’installation du pilote sur le CD-ROM
« Pilotes d’impression et manuels ».
• Per informazioni dettagliate sull’installazione
del driver della stampante, vedere la Guida
all’installazione del driver sul CD-ROM
“Printer Drivers and Manuals”.
• Para más información sobre cómo instalar
el driver de impresora, consulte la Guía de
instalación del driver del CD-ROM “Printer
Drivers and Manuals”.
• Voor meer informatie over het installeren
van het printerstuurprogramma, zie
Installatiehandleiding stuurprogramma op
de meegeleverde cd-rom “Printer Drivers and
Manuals”.
• Para mais informações acerca da instalação
do driver de impressão, consulte o Driver
Installation Guide no CD-ROM “Printer Drivers
and Manuals”.
• Para obter informações sobre instalação do driver
de impressão, consulte Driver Installation Guide
no CD-ROM “Printer Drivers and Manuals”.
• Для получения сведений об установке
драйвера принтера см. Руководство по
установке драйвера на компакт-диске
“ДрайверыпринтераиРуководства”.
Connecting the Printer
Verbinden des
Druckers
Connecter l’imprimante
Collegare la stampante
Conectividad de la
impresora
De printer verbinden
Ligar a impressora
Conectar a impressora
Подключение
принтера
CQT631
• For details about the machine’s settings or
networkcongurations,seetheonlinemanuals
available on our web site (http://www.ricoh.
com/downloads/).
• Einzelheiten zu den Geräteeinstellungen oder
derNetzwerkkongurationndenSieinden
Online-Handbüchern auf unserer Website
(http://www.ricoh.com/downloads/).
• Pour plus d’informations sur les paramètres
de l’appareil ou les configurations réseau,
reportez-vous aux manuels disponibles sur note
site Web (http://www.ricoh.com/downloads/).
• Per informazioni sulle impostazioni del
dispositivoosullacongurazionedirete
consultare i manuali online disponibili sul
sito web (http://www.ricoh.com/downloads/).
• Para más información sobre los ajustes de la
máquinaolasconguracionesdered,consulte
los manuales online disponibles en nuestro sitio
web (http://www.ricoh.com/downloads/).
• Voor gedetailleerde informatie over
apparaatinstellingen of netwerkconguratie,
zie de online handleidingen op onze website
(http://www.ricoh.com/downloads/).
• Para detalhes sobre as definições do
equipamento ou configurações de rede,
consulte os manuais online disponíveis
no nosso website (http://www.ricoh.com/
downloads/).
• Paraobtermaisinformaçõessobreasdenições
do equipamento ou congurações de rede,
consulte os manuais on-line disponíveis em
nosso site (http://www.ricoh.com/downloads/).
• Для получения сведений о настройках
аппарата или сетевых настройках см.
онлайнруководства,доступныенанашем
веб-сайте(http://www.ricoh.com/downloads/).
Turning on the Power
Einschalten der
Stromversorgung
Mettre l’appareil sous
tension
Accendere
l’alimentazione
Conexión y encendido
Het apparaat aanzetten
Ligar a alimentação
Ligar o equipamento
 Включениепитания
2
1
DBQ053
DBQ054
© 2014
EN GB EN US DE DE FR FR
IT IT ES ES NL NL PT PT
PT BR RU RU
M187-7517

Ricoh SP 6430DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	PCL 5c, PCL 6, PostScript 3
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	500 sheets
Maximum input capacity	2100 sheets
Maximum print size	297 x 432 mm
Duplex media weight	56 - 162 g/m²
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper, Transparencies
Paper tray media weight	56 - 220 g/m²
Duplex media weight (imperial)	15 - 43 lbs
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	15 - 59 lbs
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Maximum internal memory	1024 MB
Display	LCD
Product color	Grey, White
Display number of lines	4 lines
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.45 W
Power consumption (printing)	554 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003 R2, Windows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	392 mm
Width	459 mm
Height	347.5 mm
