Ricoh SP C261DNW User Manual

10
Easy Setup Using a PIN Code
● Before doing the following procedure, install the printer
driver according to the procedure on page 5
"Connecting the Machine (USB/Network)".
● Make sure the Ethernet cable is not connected to the
machine.
● In Steps 17 to 20, congure each setting within two
minutes.
● To establish a connection using the PIN code, use a
computer that is connected to the router (access point).
● The following item is necessary to set up a wireless
connection.
● Router (access point)
1. Check that the router (access point) is working correctly.
2. Open the PIN code configuration window (web page) for the
router (access point) on your computer.
3. Press the [Menu] key.
DUE129
4. Press the [ ] or [ ] key to select [Host Interface], and then
press the [OK] key.
5. Press the [ ] or [ ] key to select [Network Setting], and
then press the [OK] key.
6. Press the [ ] or [ ] key to select [Wi-Fi Config.], and then
press the [OK] key.
7. Press the [ ] or [ ] key to select [Wi-Fi], and then press
the [OK] key.
8. Press the [ ] or [ ] key to select [Active], and then press
the [OK] key.
9. Press the [Menu] key to return to the Initial screen.
10. Turn off the machine, and then turn it back on.
11. Press the [Menu] key.
DUE129
12. Press the [ ] or [ ] key to select [Host Interface], and then
press the [OK] key.
13. Press the [ ] or [ ] key to select [Network Setting], and
then press the [OK] key.
14. Press the [ ] or [ ] key to select [Wi-Fi Config.], and then
press the [OK] key.
15. Press the [ ] or [ ] key to select [WPS], and then press the
[OK] key.
16. Press the [ ] or [ ] key to select [PIN], and then press the
[OK] key.
17. Check the PIN code.
Write down the PIN code in case you might forget it.
18. Enter the machine’s PIN code (8 digits) on the router
(access point)’s web page.(The web page accessed in Step
2)

Ricoh SP C261DNW Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	30000 pages per month
Number of print cartridges	4
Page description languages	PCL 6, PDF, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1300 W
Power consumption (ready)	58.3 W
Power consumption (printing)	- W
Energy Star Typical Electricity Consumption (TEC)	1.233 kWh/week
Display	LCD
Product color	Black, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.9 Mavericks
Linux operating systems supported	Red Hat Enterprise Linux WS 4.0, Red Hat Enterprise Linux WS 5.0, Red Hat Enterprise Linux WS 6.0
Other operating systems supported	IBM AIX 6.1, IBM AIX 7.1
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Paper input type	Paper tray
Total input capacity	251 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Paper tray media types	-
Paper tray media weight	60 - 160 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Processor family	Intel® Celeron® M
Processor frequency	350 MHz
Maximum internal memory	256 MB
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	320 mm
Weight	23800 g
