9
FEATURES
Fig. 2
PRODUCT SPECIFICATIONS
Air Tank Capacity .......................................................5 gal.
Air Pressure .................................................... 135 psi max.
Air Delivery ........................................... 4.6 SCFM @ 90 psi
Gauges ..........................................................2 in. diameter
Input ............................. 120 V, 60 Hz, AC only, 12.5 Amps
Net Weight................................................................ 89 lbs.
ON/OFF
SWITCH
SAFETY
VALVE
PRESSURE
REGULATOR KNOB
TANK
PRESSURE
GAUGE
REGULATOR
PRESSURE
GAUGE
HANDLE
QUICK CONNECT
UNIVERSAL FITTINGS
AIR FILTER
OIL DRAIN
VALVE
OIL DIPSTICK
HANDLE
RELEASE
KNOB
BUILT-IN
CORD
WRAP
DRAIN VALVES
