User’s Guide for DS1000E, DS1000D Series
5-3
Range
(Sec/div)
5ns/div~50s/div, DS1052X
1-2-5 Sequence
Sample Rate and
Delay Time
Accuracy
±50ppm (any interval ≥1ms)
Vertical
A/D converter 8-bit resolution, all channels samples simultaneously
Volts/div Range 2mV/div~10V/div at input BNC
Maximum Input Maximum input voltage on analog channel
CAT I 300Vrms, 1000Vpk; instantaneous overvoltage
1000Vpk
CAT II 100Vrms, 1000Vpk
RP2200 10:1：CAT II 300Vrms
RP3300A 10:1：CAT II 300Vrms
Offset Range ±40V (250mV/div~10V/div)
±2V (2mV/div~245mV/div)
Analog Bandwidth 100MHz (DS1102D,DS1102E)
50MHz (DS1052D, DS1052E)
Single-shot
Bandwidth
100MHz (DS1102D, DS1102E)
50MHz (DS1052D, DS1052E)
Selectable Analog
Bandwidth Limit
(typical)
20MHz
Lower Frequency
Response (AC
–3dB)
≤5Hz (at input BNC)
Rise Time at BNC,
(typical)
<3.5ns, <7ns,
(respectively at 100MHz, 50MHz)
Dynamic range ±5div
DC Gain Accuracy 2mV/div-5mV/div:
±4% (Normal or Average acquisition mode)
10mV/div-10V/div:
±3% (Normal or Average acquisition mode)
DC Measurement
Accuracy, Average
Average of ≥16 Waveforms with vertical position at zero:
±(DC Gain Accuracy×reading+0.1div+1mV)
