Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-47
Window Layout
Four Window (S11); UD Window (S21/DTF)
Mode Setup
Global CF
Off, 0 Hz
Meas
Measurement
Function
S11
Meas Setup (S11)
Average Count
100
Reference Level
0.00 dBm
Aperture Step
Width
10
Port Extension
Off
Port 1 Delay
0.00 ns
Unit
meter
Port 1 Length
0.00 cm
Port 1 Velocity
Factor
1
Port 1 Specific Loss
0.00 dB/m
Cal Kits
CK106A
Cal Type
Open
Offset Length
14.89 mm
C0
-2.71 fF
C1
2.478 fF/GHz
C2
-1.97e-1 fF/GHz
2
C3
-2.09e-2 fF/GHz
3
Meas Setup（S21）
Avg Number
100
Ref Value
-10.00 dBm
Aperture Step
Width
10
Port Extension
Off
Unit
meter
Port 1 Delay
0.00 ns
Port 1 Length
0.00 cm
Port 1 Velocity
Factor
1
Port 1 Specific Loss
0.00 dB/m
Port 2 Delay
0.00 ns
Port 2 Length
0.00 cm
Port 2 Velocity
Factor
1
Port 2 Specific Loss
0.00 dB/m
Cal Kits
CK106A
Cal Type
Open
