3
Specifications
Model PM262 PM262B PM262X PM282 PM282B PM282X
Nominal Diameter - inch
(mm)
6
(152)
6
(152)
6
(152)
8
(203)
8
(203)
8
(203)
Description
2-Way 2-Way 2-Way 2-Way 2-Way 2-Way
Nominal Impedance (Ohms)
4Ω 4Ω 4Ω 4Ω 4Ω 4Ω
Frequency Response (Hz)
53-22kHz 53-22kHz 53-22kHz 48-22kHz 48-22kHz 48-22kHz
Voice Coil Diameter - inch
(mm)
1.0
(25.4)
1.0
(25.4)
1.0
(25.4)
1.25
(32.3)
1.25
(32.3)
1.25
(32.3)
Power Handling - Watts
(RMS/Peak)
75/150 75/150 75/150 100/200 100/200 100/200
Fs - Free Air Resonance (Hz)
60 60 60 50 50 50
Qts
0.64 0.64 0.64 0.53 0.53 0.53
Vas - cu. ft.
(Liter)
0.445
(12.6)
0.445
(12.6)
0.445
(12.6)
1.06
(30)
1.06
(30)
1.06
(30)
Sensitivity (1W/1M)
88dB 88dB 88dB 90dB 90dB 90dB
Sensitivity (2.83V/1M)
91dB 91dB 91dB 93dB 93dB 93dB
Xmax - inch
(mm)
0.2
(5)
0.2
(5)
0.2
(5)
0.28
(7)
0.28
(7)
0.28
(7)
Mounting Diameter
5.2
(131)
5.2
(131)
5.2
(131)
7.1
(180)
7.1
(180)
7.1
(180)
Mounting Depth
2.8
(71)
2.8
(71)
2.8
(71)
3.4
(87)
3.4
(87)
3.4
(87)
Grille/Trim Ring
YES YES YES YES YES YES
See page 4 for additional dimensions
CEA 2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. This means your speaker has the capacity to handle
power under continuous demand, not instantaneous power handling that over time can damage voice coils.
VERIFIED WITH KLIPPEL
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be trained and certified by
Klippel prior to using the three separate Klippel systems to design, develop and test. Rockford Fosgate has made the investment in Klippel to
deliver the best possible speakers and subwoofers to their customers.
