Rockwell Automation 1734-FPD User Manual

POINT I/O Field Potential Distributor Modules 9
Publication 1734-IN059D-EN-E - April 2013
Wire the Module
WARNING: If you connect or disconnect wiring while the field-side power is
on, an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
ATTENTION: Do not wire more than 2 conductors on any single terminal.
NC = No connection
Chas gnd = Chassis ground
C = Common
V = Supply
NC
Chas gnd
C
V
NC
C
V
Chas gnd
45728
