Embedded Analog Input Specifications
Attribute Value
Number of inputs 4 differential or single-ended
Analog normal operating ranges
(1)
(1)
The over-range flag will come on when the normal operating range is exceeded. The embedded HSC will continue to convert
the analog input up to the maximum full scale range. The flag automatically resets when within the normal operating range.
Voltage: 0 to 10V DC
Current: 0 to 20 mA
Full Scale Analog Ranges
(1)
Voltage:0 to 10.5V DC
Current: 0 to 21 mA
Converter type Successive approximation
Resolution, max 8 bits plus sign (Sign is always positive.)
Response speed per channel 5 ms
Rated working voltage
(2)
30V AC/30V DC
Common mode voltage
(3)
10V DC maximum per channel
Common mode rejection Greater than 60 dB at 60 Hz at 10V between inputs and analog common
Normal mode rejection ratio None
Input impedance Voltage Terminal: 150K Ω (nominal)
Current Terminal: 150 Ω (nominal)
Accuracy, overall at 25°C
(4)
Voltage Terminal: ±0.7% full scale
Current Terminal: ±0.6% full scale
Accuracy, overall at 0 to 60°C Voltage Terminal: ±0.9% full scale
Current Terminal: ±0.8% full scale
Accuracy Drift with Temperature Voltage Terminal: ±0.006% per °C
Current Terminal: ±0.006% per °C
Calibration Not required. Accuracy is guaranteed by components.
Non-linearity (in percent full scale) ±0.4%
Repeatability
(5)
±0.4%
Input channel configuration Via wiring of devices and the analog I/O Module Properties dialog box
in RSLogix
5000 software.
Maximum overload at input
terminals
(6)
Voltage Terminal: 20V continuous, 0.1 mA
Current Terminal: 32 mA continuous, +5V DC
Channel Diagnostics Over-range by bit reporting
Isolation voltage 30V (continuous), Basic Insulation Type
Type tested at 500V AC for 60 s; Inputs to System Backplane and
Outputs to System Backplane
