CompactLogix Packaged Controllers 5
Publication 1769-IN082A-EN-P - July 2008
Example of Expansion I/O Calculation:
In this example, these expansion I/O modules and bus current draws are planned
for use with the 1769-L23E-QBFC1B packaged controller.
The total bus current draw of the Compact I/O modules (310 mA) is less than the
total available bus current of the packaged controller (450 mA). These planned
expansion I/O modules are within the limits of the 1769-L23E-QBFC1B packaged
controller.
Parts (included with the packaged controller)
These components are included with your CompactLogix packaged controller.
Parts (optional, not included with the packaged controller)
In addition to the parts included with the packaged controller, you may choose to
use these components specific to your application.
Planned Expansion I/O Module
Bus Current Draw, max
(1)
(1)
The maximum bus current draw specification for each Compact I/O module is available in the Compact I/O Selection Guide,
publication
1769-SG002. This publication also provides further explanation of and a table for the calculation of Compact I/O
power supply requirements.
1769-OV16 Sink Output Module 200 mA
1769-IF4 Analog Input Module 105 mA
1769-ECR End Cap 5 mA
Total Bus Current Draw: 310 mA
Cat. No. Part
1747-KY Key
1769-BA Battery
1769-ECR End cap
If using Then use this component
RS-232 port to connect to the packaged
controller.
1756-CP3 or 1747-CP3 serial cable.
EtherNet/IP port to connect to the packaged
controller.
Standard Ethernet cable with an RJ45 connector, or, for
industrial grade requirements, 1585J Ethernet
connectivity media.
Panel mount method to install the packaged
controller.
4…8 M4 or #8 panhead screws (depending on the number
of expansion modules used).
