84 Rockwell Automation Publication 440R-UM013F-EN-P - July 2021
Appendix B Regulatory Approvals
Specifications are applicable only if the safety function is demanded at least
once within six months. All diagnostic tests are conducted at least before next
demand. At mission time (TM), the proof test interval (PTI) is assumed.
Components failure rates are according to SN29500.
SIL Rating
Safety relays meet the requirements in Table 19 in accordance with
IEC/EN 61508 and IEC 62061.
Performance Level/Category
Safety relays can be used in safety systems that meet up to Category 4 and
Performance Level PLe in accordance with ISO 13849-1.
Table 19 - SIL Rating
440R-S13R2
(CI)
440R-D22R2
(DI)
440R-D22S2
(DIS)
440R-EM4R2
(EM)
440R-EM4R2D
(EMD)
440R-S12R2
(SI)
PFHd (1/h) 4.39 E-09 4.49 E-09 4.39 E-09 1.52 E-09 4.55 E-09 3.98 E-09
Safety Integrity Level Claim
Limit
3
Mode of Operation High demand
Hardware Fault Tolerance 1
Safe Failure Fraction 99%
Table 20 - Performance Level/Category
440R-S13R2
(CI)
440R-D22R2
(DI)
440R-D22S2
(DIS)
440R-EM4R2
(EM)
440R-EM4R2D
(EMD)
440R-S12R2
(SI)
MTTFd 164 355 484 190 165 262
Category Up to 4
Performance Level Up to e
DC avg 99%
Mission Time 20 years
Days of Operation 365 days
Hours of Operation 24 hr
T cycle 8 hr / 8.28 s
