Appendix A ControlLogix Network Device Status Indicators
Figure 4 - 1756-EN2TP (Dual-port Module)
Figure 5 - 1756-EN2TSC (Single-port Module)
Figure 6 - 1756-EN4TR (Dual-port Module)
(1)
(1) Parallel Redundant Protocol and Redundant Adapter features are not available in the initial release. Check the
Product Compatibility and Download Center (PCDC)
to see if it is available in your firmware revision.
32730
1756-EN2TP
Link Status
Indicators (LINK)
OK Status Indicator
Network Status Indicator (NET)
Module Status Display
VPN
Network Status Indicator (NET)
OK Status Indicator
Module Status Display
Link Status
Indicator (LINK)
Link Status
Indicators (LINK)
Network Status Indicator (NET)
OK Status Indicator
Module Status Display
Parallel Redundant Protocol
Status Indicator
Redundant Adapter Status Indicator
SD Card Status Indicator
