Rockwell Automation PanelView Plus 1000 Installation Instructions

PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules 27
Publication 2711P-IN001I-EN-P - November 2009
Startup Error Messages
When an error occurs, the terminal displays an error number with a text message. The word
ERROR! appears under the message in different languages.
Error # Message Description Recommended Corrective Action
1 RAM Test RAM test failure. Reset the terminal. If error persists, reseat the
SO-DIMM RAM module. If error still persists, replace
the logic module.
23 Internal CF Error programming
the new OS firmware
to internal
CompactFlash card.
Reload the firmware. If error persists, replace the
internal CompactFlash card. If error still persists,
replace the logic module.
24 CRC Check Checksum of the OS
firmware failed.
Reload the firmware. If error persists, replace the
internal CompactFlash card. If error still persists,
replace the logic module.
30 Watchdog Test Watchdog test
failure.
Reload the firmware. If error persists, replace the
logic module.
31 Stuck Key Function key failure. Check that nothing is pressed against a key. Reset
the terminal without key presses. If error persists,
replace the display module.
31.5 Stuck Touch Touch screen failure. Check that nothing is pressed against the touch
screen. Reset the terminal without pressing the touch
screen. If error persists, replace the display module.
32 Battery Test Battery failure. Replace the battery. If error persists, replace the logic
module.
33.5 NVRAM Access Nonvolatile memory
failure.
Upgrade the system firmware to revision 3.10.03 or
later.
40 EXE Check System OS firmware
is missing or corrupt.
Reload the firmware. If error persists, replace the
internal CompactFlash card. If error still persists,
replace the logic module.
50 External CF Error loading the OS
firmware from the
external
CompactFlash card.
Reload the firmware. If error persists, replace the
external CompactFlash card and attempt the
firmware upgrade again.
# Displayed Message
ERROR! FEHLER! ERREUR! ERRORE!
