7
CUBE-30
EXPLODED VIEW PARTS LIST(CHASSIS)
[PART]
*
i SCREW M3X6 is not included in PCB ASSY.
[SCREW]
No
Part Code Part Name Description Q’ty
1 SD000015 AC CORD SP-502B 240V 1
1 SD000014 AC CORD SP-301 117V 1
1 SD000012 AC CORD SP-023 230V 1
1 SD000016 AC CORD SP-60 230VE 1
2 SD000030 CHASSIS 1
3 72360705 CORD HOOK 2
4 2249752100 PUSH BUTTON BLACK #521 1
5 SD000043 KNOB 9
6 12369410RT AC CORD HOLDER 1702B 2
7 SD000053
PCB SPACER
*
SCC-6 94V-0
3
8 SD000036 HEATSINK 1
9 SD000001 PCB ASSY 100/117V 1
10 02897801 SEESAW SWITCH SDDJE13200 94V-0 1
11 SD000064 TRANSFORMER ST-11544 230V/240V 1
11 SD000065 TRANSFORMER ST-11545 100V/117V 1
No Part Code Part Name Description Q’ty
a 17048631 VR ACCESSORY WASHER M9 9
b 17048630 VR ACCESSORY NUT M9 9
c 40345534 SCREW M4X25 PAN MACHINE W/SW+PW BZC 2
d 40011767 FLANGE HEX NUT M4 FE CM 4
e 40011756 FLANGE HEX NUT M3 ZC 4
f SD000042 JACK NUT 4
g SD000018 SCREW 4X12 BINDING MACHINE BZC 2
h 40011889 EXTERNAL TOOTH WASHER M4 FECM 3
i 40017934 SCREW M3X6 PAN MACHINE W/SW+PW FE ZC 4
j 40010301 SCREW M3X20 BINDING MACHINE BZC 2
k 40012878 SCREW M3X10 PAN MACHINE W/SW+PW ZC 2
l 40012945 SCREW M3X6 PAN MACHINE W/SW+PW BZC 2
m 22150518 STANDOFF HEX.BOSS 5.5X15 M3 2
n SD000052 SCREW 4X8 PAN MACHINE BZC 3
o 40347534 M4 SPRING WASHER BZC 2
