8
Introduction
Panel Descriptions
1. [Power] Switch
This switch turns the unit on/off (p. 11).
2. [Volume] Knob
Adjusts the volume (p. 12).
3. [Reverb] Button
Used to add reverberation to the sound (p. 17).
Tone
4. Tone Buttons
The following five buttons are collectively referred to as
the Tone buttons. These are used to select the tone to
played via the keyboard (p. 15).
[Piano] Button
[E.Piano] Button
[Harpsichord] Button
[Organ] Button
[Strings] Button
5. [Variation] Button
This is used in combination with the Tone buttons to
select the instrument sounds to be played with the
keyboard (p. 15).
Key Touch
6. [Light] Button
[Heavy] Button
These change the touch sensitivity, or response of the
keys (p. 19).
Recorder
7. [Play] Button
Starts playback of recorded performance (p. 18).
8. [Rec] Button
Records your performance (p. 18).
9. [Demo] Button
This plays the demo songs (p. 13, p. 14).
Power
1
Power
23456789
F-50_e.book 8 ページ ２００５年２月２日 水曜日 午後５時１１分
