Roland FP-7F Implementation Guide

7
ppH Controlled parameter
rrH Controlled range
F7H EOX (End Of Exclusive)
pp=0 Pitch Control
rr = 28H - 58H -24 - +24 [semitones]
pp=1 Filter Cutoff Control
rr = 00H - 7FH -9600 - +9450 [cents]
pp=2 Amplitude Control
rr = 00H - 7FH 0 - 200 [%]
pp=3 LFO Pitch Depth
rr = 00H - 7FH 0 - 600 [cents]
pp=4 LFO Filter Depth
rr = 00H - 7FH 0 - 2400 [cents]
pp=5 LFO Amplitude Depth
rr = 00H - 7FH 0 - 100 [%]
○Controller
Status Data byte Status
F0H 7FH, 7FH, 09H, 03H, 0nH, ccH, F7H
ppH, rrH
Byte
Explanation
F0H Exclusive status
7FH ID number (Universal Realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (Controller Destination Setting)
03H Sub ID#2 (Control Change)
0nH MIDI Channel (00 - 0F)
ccH Controller number (01 - 1F, 40 - 5F)
ppH Controlled parameter
rrH Controlled range
F7H EOX (End Of Exclusive)
pp=0 Pitch Control
rr = 28H - 58H -24 - +24 [semitones]
pp=1 Filter Cutoff Control
rr = 00H - 7FH -9600 - +9450 [cents]
pp=2 Amplitude Control
rr = 00H - 7FH 0 - 200 [%]
pp=3 LFO Pitch Depth
rr = 00H - 7FH 0 - 600 [cents]
pp=4 LFO Filter Depth
rr = 00H - 7FH 0 - 2400 [cents]
pp=5 LFO Amplitude Depth
rr = 00H - 7FH 0 - 100 [%]
○Scale/Octave Tuning Adjust
Status Data byte Status
F0H 7EH, 7FH, 08H, 08H, ffH, ggH, F7H
hhH, ssH...
Byte
Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
08H Sub ID#1 (MIDI Tuning Standard)
08H Sub ID#2 (scale/octave tuning 1-byte form)
ffH Channel/Option byte1
bits 0 to 1 = channel 15 to 16
bit 2 to 6 = Undefined
ggH Channel byte2
bits 0 to 6 = channel 8 to 14
hhH Channel byte3
bits 0 to 6 = channel 1 to 7
ssH 12 byte tuning offset of 12 semitones from C to B
00H = -64 [cents]
40H = 0 [cents] (equal temperament)
7FH = +63 [cents]
F7H EOX (End Of Exclusive)
○Key-Based Instrument Controllers
Status Data byte Status
F0H 7FH, 7FH, 0AH, 01H, 0nH, F7H
kkH, nnH, vvH...
Byte
Explanation
F0H Exclusive status
7FH ID number (Universal Realtime Message)
7FH Device ID (Broadcast)
0AH Sub ID#1 (Key-Based Instrument Control)
01H Sub ID#2 (Controller)
0nH MIDI Channel (00 - 0FH)
kkH Key Number
nnH Control Number
vvH Value
F7H EOX (End Of Exclusive)
nn=07H Level
vv = 00H - 7FH 0 - 200 [%] (Relative)
nn=0AH Pan
vv = 00H - 7FH Left - Right (Absolute)
nn=5BH Reverb Send
vv = 00H - 7FH 0 - 127 (Absolute)
nn=5DH Chorus Send
vv = 00H - 7FH 0 - 127 (Absolute)
* This parameter effects drum instruments only.
●Universal Non-realtime System Exclusive Messages
○Identity Request Message
Status Data byte Status
F0H 7EH, 10H, 06H, 01H F7H
Byte
Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
10H Device ID
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End Of Exclusive)
* Device ID = 10H or 7FH
●Data transmission
This instrument can receive the various parameters using System Exclusive
messages.
The exclusive message of GS format data has a model ID of 42H and a device
ID of 10H (17), and it is common to all the GS devices.
○Data set 1DT1
This is the message that actually performs data transmission, and is used when
you wish to transmit the data.
Status
Data byte Status
F0H 41H, 10H, 42H, 12H, aaH, bbH, F7H
ccH, ddH, ... eeH, sum
Byte
Explanation
F0H Exclusive status
41H ID number (Roland)
10H Device ID
42H Model ID (GS)
12H Command ID (DT1)
aaH Address MSB: upper byte of the starting address of
the transmitted data
bbH Address: middle byte of the starting address of the
transmitted data
ccH Address LSB: lower byte of the starting address of
the transmitted data
ddH Data: the actual data to be transmitted. Multiple
bytes of data are transmitted starting from the
address.
:
