Roland JD-Xi Midi Implementation

3
6
RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specied by RPN
ll = lower byte (LSB) of parameter number specied by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are
extended.
When using RPNs, rst RPN (Controller numbers 100 and 101; they can be
sent in any order) should be sent in order to select the parameter,
then Data Entry (Controller numbers 6 and 38) should be sent to set
the value. Once RPN messages are received, Data Entry messages that
is received at the same MIDI channel after that are recognized as
changing toward the value of the RPN messages. In order not to make
any mistakes, transmitting RPN Null is recommended after setting
parameters you need.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specied in semitone steps.
*
The Part Pitch Bend Range parameter (PROG:PITCH)
will change.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)
*
The Part Fine Tune parameter (PROG:PITCH) will
change.
00H, 02H mmH, llH Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)
ll: ignored (processed as 00H)
*
The Part Coarse Tune parameter (PROG:PITCH) will
change.
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as “unspecied.” Once
this setting has been made, subsequent
Parameter values that were previously set will not
change.
mm, ll: ignored
7
Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H - FH (ch.1 - 16)
pp = Program number: 00H - 7FH (prog.1 - prog.128)
*
Not received when the Receive Program Change parameter (SysEx) is
OFF.
7
Channel Pressure
Status 2nd byte
DnH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Channel Pressure: 00H - 7FH (0 - 127)
*
Not received when the Receive Channel Press parameter (SysEx) is
OFF.
7
Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192
- 0 - +8191)
*
Not received when the Receive Pitch Bend parameter (SysEx) is OFF.
9
Channel Mode Messages
7
All Sounds O (Controller number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
*
When this message is received, all notes currently sounding on the
corresponding channel will be turned o.
7
Reset All Controllers (Controller
number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
*
When this message is received, the following controllers will be
set to their reset values.
Controller Reset value
Pitch Bend Change +/-0 (center)
Channel Pressure 0 (o)
Modulation 0 (o)
Expression 127 (max)
However the controller will be at minimum.
Hold 1 0 (o)
RPN unset; previously set data will not change
NRPN unset; previously set data will not change
7
All Notes O (Controller number 123)
Status 2nd byte 3rd byte
BnH 7BH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
*
When All Notes O is received, all notes on the corresponding
channel will be turned o. However, if Hold 1 is ON, the sound will
be continued until these are turned o.
7
OMNI OFF (Controller number 124)
Status 2nd byte 3rd byte
BnH 7CH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
*
The same processing will be carried out as when All Notes O is
received.
7
OMNI ON (Controller number 125)
Status 2nd byte 3rd byte
BnH 7DH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
*
The same processing will be carried out as when All Notes O is
received. OMNI ON will not be turned on.
7
MONO (Controller number 126)
Status 2nd byte 3rd byte
BnH 7EH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = mono number: 00H - 10H (0 - 16)
*
The same processing will be carried out as when All Notes O is
received.
*
Not received on the Analog part.

Roland JD-Xi Specifications

General

Pitch wheel	Yes
Product type	Digital/analog synthesizer
Product color	Black
Sound effects	Compression, Delay, Flanger/Digital Signal Processing (DSP), Phaser, Reverberation
Backlight color	Red
Keyboard number of keys	37
Maximum polyphony (notes)	129
Reverberation effects quantity	6
USB ports quantity	1
Display type	LCD
Display number of lines	2 lines
Display number of characters	16
Power source type	AC

Weight and Dimensions

Depth	245 mm
Width	575 mm
Height	85 mm
Weight	2200 g
