2
MIDI Implementation
RPN MSB/LSB (Controller number 100, 101)
Status
2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any order)
should be sent in order to select the parameter, then Data Entry (Controller numbers 6 and 38)
should be sent to set the value. Once RPN messages are received, Data Entry messages that is
received at the same MIDI channel after that are recognized as changing toward the value of
the RPN messages. In order not to make any mistakes, transmitting RPN Null is recommended
after setting parameters you need.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specified in semitone steps.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192
cent)
00H, 02H mmH, llH Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)
ll: ignored (processed as 00H)
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as “unspecified.” Once this setting has been made, subsequent
Parameter values that were previously set will not change.
mm, ll: ignored
Program Change
Status
2nd byte
CnH ppH
n = MIDI channel number:0H - FH (ch.1 - 16)
pp = Program number:00H - 7FH (prog.1 - prog.128)
* Not received when the Receive Program Change parameter (SYSTEM Common MIDI) is
OFF.
Channel Pressure
Status
2nd byte
DnH vvH
n = MIDI channel number:0H - FH (ch.1 - 16)
vv = Channel Pressure:00H - 7FH (0 - 127)
Pitch Bend Change
Status
2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number:0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value:00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
Channel Mode Messages
* Not received in when the Receive Switch parameter (SYSTEM Common MIDI) is OFF.
All Sounds Off (Controller number 120)
Status
2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, all notes currently sounding on the corresponding channel
will be turned off.
Reset All Controllers (Controller number 121)
Status 2nd byte 3rd byte
BnH 79H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, the following controllers will be set to their reset values.
Controller Reset value
Pitch Bend Change +/-0 (center)
Polyphonic Key Pressure 0 (off)
Channel Pressure 0 (off)
Modulation 0 (off)
Breath Type MSB 0 (min)
Breath Type LSB 0 (min)
Expression 127 (max)
However the controller will be at minimum.
Hold 1 0 (off)
Sostenuto 0 (off)
Soft 0 (off)
Hold 2 0 (off)
General Purpose Controller 1 MSB 0 (min)
General Purpose Controller 2 MSB 0 (min)
General Purpose Controller 3 MSB 0 (min)
General Purpose Controller 4 MSB 0 (min)
General Purpose Controller 1 LSB 0 (min)
General Purpose Controller 2 LSB 0 (min)
General Purpose Controller 3 LSB 0 (min)
General Purpose Controller 4 LSB 0 (min)
General Purpose Controller 5 0 (min)
General Purpose Controller 6 0 (min)
General Purpose Controller 7 0 (min)
General Purpose Controller 8 0 (min)
RPN unset; previously set data will not change
All Notes Off (Controller number 123)
Status 2nd byte 3rd byte
BnH 7BH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When All Notes Off is received, all notes on the corresponding channel will be turned off.
However, if Hold 1 or Sostenuto is ON, the sound will be continued until these are turned
off.
OMNI OFF (Controller number 124)
Status 2nd byte 3rd byte
BnH 7CH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received.
OMNI ON (Controller number 125)
Status 2nd byte 3rd byte
BnH 7DH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* The same processing will be carried out as when All Notes Off is received. OMNI ON will
not be turned on.
