Royal Sovereign FS-44P User Manual

FS-44P
7
4. Remove coin tubes. Place the coin wrappers into the correct tubes. It is very important that the coin wrappers be
inserted all the way to the bottom of the tubes and that they do not extend above the top edge of the tube. If they extend
above the top edge of the tube, coins will not sort properly into the wrappers.
5. Return all sixteen tubes to the proper position. The coin tubes can only be inserted right side up. The tubes are labeled
on the inside base for each denomination: Q (Quarters),
N (Nickels), P (Pennies), D (Dimes).
NOTE: BECAUSE PENNIES AND DIMES ARE VERY CLOSE IN SIZE AND THICKNESS, THEY MAY SOMETIMES SORT INTO
OPPOSITE TUBES.
6. Turn the power switch on, located on the right side of the machine.
7. Press the RUN/STOP button to start the machine.
8. You will hear a "ticking" sound. This is the anti-jam device.
9. Drop the coins into the collection opening.
10. Coins will automatically start sorting into the first row.
11. Press the #/$ button at any time to switch from total dollar amount view or individual coin count view.
12. When a coin tube is full, the machine will stop temporarily to slide another coin tube into position. When an entire row of
one denomination is full, an alarm will sound and that row will automatically slide out.
13. Take out the full coin tubes and replace them with empty wrappers. Return the tubes back in place and push them back
so that the machine can start sorting into the first row again.
14. The digital counter will reset for that coin denomination but will continue counting the dollar amount until the CLEAR
botton is pushed.
15. Press the RUN/STOP button to restart.
16. To remove filled wrappers, pull up on the inside edge of the plastic tube. Then push the coin wrapper up from the
bottom of the tube. Fold inward the edges of the wrapper.
17. At any time during or after sorting you can view the LCD Display for your total dollar amount or your individual coin
count.
18. Press the CLEAR button to reset the display.
19. When you are finished sorting press the RUN/STOP button to stop the machine and then turn off the machine using the
power switch on the right side.
20. Be sure that the Hopper Lid Screw is always fastened when operating the machine. A loose lid may reduce performance.

Royal Sovereign FS-44P Specifications

General

Type	Sorting machine
Product color	Black, Grey
Packaging speed	- pieces/min
Detecting function	Yes
Input voltage	120 V
Power consumption (typical)	5.5 W
Package depth	381 mm
Package width	228.6 mm
Package height	297.1 mm
Package weight	4309 g
Master (outer) case width	476.2 mm
Master (outer) case height	609.6 mm
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Depth	340.3 mm
Width	195.5 mm
Height	256.5 mm
Weight	3855 g
