Ryobi CS30, SS30, BC30 User Manual

Page 18
OPERATION
STARTING AND STOPPING
See Figures 21 - 23.
TO START A COLD ENGINE:
DO NOT squeeze the throttle trigger until the engine starts
and runs.
n Lay the trimmer on a flat, bare surface.
n PRIME - Press the primer bulb 7 times.
n SET the start lever to the START position.
n PULL the rope until the engine starts.
n Allow the engine to run for 15 seconds.
n Squeeze trigger lock and throttle trigger.
NOTE: Squeezing the throttle trigger releases the start lever
to the RUN position.
TO START A WARM ENGINE:
PULL the rope until the engine starts.
TO STOP THE ENGINE:
Press and hold the switch in the stop “ ” position until the
engine stops.
Fig. 22
Fig. 21
THROTTLE
TRIGGER
IGNITION
SWITCH
THROTTLE TRIGGER
IGNITION
SWITCH
Fig. 23
PRIMER BULB
START
POSITION
RUN
POSITION
START LEVER
START LEVER
TRIGGER
LOCK
TRIGGER
LOCK
