5 — English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Recycle Symbol
This product uses lithium-ion (Li-ion) batteries. Local, state, or
federal laws may prohibit disposal of batteries in ordinary trash.
Consult your local waste authority for information regarding
available recycling and/or disposal options.
Direct Current Type or a characteristic of current
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
hrs Hours Time
SYMBOLS
FEATURES
KNOW YOUR LAWN MOWER
See Figure 1.
The safe use of this product requires an understanding of the
information on the product and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
BATTERY COVER
The battery cover protects the battery port from moisture
and debris.
GRASS CATCHER
The grass catcher collects grass clippings and prevents
them from being discharged across your lawn as you mow.
HEIGHT ADJUSTMENT LEVER
The height adjustment lever provides cutting height
adjustments.
MULCHING PLUG
Your mower is equipped with a mulching plug that covers
the rear discharge opening, which allows the mower blade
to cut and recut for finer clippings.
START BUTTON AND BAIL
The start button and bail are located on the upper handle of
the mower. Depress the start button then engage the bail to
start the motor. Release the bail to stop the motor.
START KEY
The start key must be inserted before the mower can be
started.
PRODUCT SPECIFICATIONS
Motor ...................................................................................................................................................................... 18 Volt DC
Cutting Path ................................................................................................................................................................... 13 in.
Height Adjustments .................................................................................................................................... 1.38 in. to 2.96 in.
Wheel Size .............................................................................................................................................5.5 in. front, 7 in. rear
