clockwise direction as viewed from the bottom of the
mower.
NOTE: Make certain all parts are replaced in the exact
order in which they were removed.
8. Torque the blade bolt down using a torque wrench (not
provided) to ensure the bolt is properly tightened.
9. The recommended torque for the blade bolt is 48–55
Nm (35–40 ft.lb.).
NOTE: Do not sharpen the blades, replace with new
item. Blades need to be properly balanced to avoid
damage and personal injury.
CLEANING THE AIR FILTER
6HH¿JXUH
)RU SURSHU SHUIRUPDQFH DQG ORQJ OLIH NHHS WKH DLU ¿OWHU
clean.
1. 5HPRYHWKHDLU¿OWHUFRYHUE\SXVKLQJGRZQWKHODWFK
while gently pulling out the cover.
5HPRYHWKHDLU¿OWHUDQGFOHDQLWLQZDUPVRDS\ZDWHU
Rinse and let dry completely.
3. $SSO\ D OLJKW FRDW RI HQJLQH RLO WR WKH DLU ¿OWHU WKHQ
squeeze it out using an absorbent cloth or paper towel.
4. 5HLQVWDOOWKHDLU¿OWHULQWRWKHDLU¿OWHUEDVH
5. 5HSODFHDQGVHFXUHWKHDLU¿OWHUFRYHU
NOTE: The filter should be replaced annually for best
performance.
FUEL CAP
WARNING
$OHDNLQJIXHOFDSLVD¿UHKD]DUGDQGPXVWEHUHSODFHG
immediately.
7KH IXHO FDS FRQWDLQV D QRQVHUYLFHDEOH ¿OWHU DQG D
check valve. A clogged fuel cap will cause poor engine
performance. If performance improves when the fuel cap
is loosened, check valve may be faulty or clogged. Replace
fuel cap if required.
CHANGING THE ENGINE OIL
6HH¿JXUH
Ensure the fuel tank is completely empty before tipping the
unit over otherwise fuel will leak out.
(QJLQHRLOVKRXOGEHFKDQJHGDIWHUHYHU\KRXUVRIXVH
Change the oil while the engine oil is still warm, but not hot.
This allows the oil to drain quickly and completely.
1. 5HPRYHWKHRLO¿OOFDSGLSVWLFN
Tip mower onto its side and allow oil to drain from the oil
¿OOKROHLQWRDQDSSURYHGFRQWDLQHU
3. 3ODFH PRZHU XSULJKW DQG UH¿OO ZLWK RLO IROORZLQJ WKH
LQVWUXFWLRQVLQWKH$GGLQJ&KHFNLQJ2LOVHFWLRQ
NOTE: Used oil should be disposed of at an approved
disposal site. See your local oil retailer for more
information.
MAINTAINING THE SPARK PLUG
6HH¿JXUH
The spark plug must be properly gapped and free of
deposits in order to ensure proper engine operation. To
check:
1. Remove spark plug boot.
Clean any dirt from around base of spark plug.
3. 5HPRYHVSDUNSOXJXVLQJDLQVSDUNSOXJVRFNHW
(not provided).
4. Inspect spark plug for damage, and clean with a wire
brush before reinstalling. If insulator is cracked or
chipped, spark plug should be replaced.
NOTE: If replacing, use the following recommended
plugs are LG F7RTC or LD F7RTC.
5. Measure plug gap. The correct gap is 0.71 mm -
0.79 mm. To widen gap, if necessary, carefully bend
the ground (top) electrode. To lessen gap, gently tap
ground electrode on a hard surface.
6. Seat spark plug in position; thread in by hand to prevent
cross-threading.
7. Tighten with wrench to compress washer. If spark plug
LVQHZ XVHWXUQ WRFRPSUHVVZDVKHUDSSURSULDWH
DPRXQW,IUHXVLQJROGVSDUNSOXJXVHWRWXUQIRU
proper washer compression.
NOTE: An improperly tightened spark plug will become
very hot and could damage the engine.
8. Reinstall spark plug boot.
MAINTAINING THE DRIVE GEAR
6HH¿JXUH
To ensure smooth operation of wheels, the wheel assembly
should be cleaned before storage.
1. Remove the nut and wheel and set aside.
Remove dust cover, e-ring, washer, pins, and wheel
gear. Clean any dirt from these items and the end of
the drive shaft by wiping with a dry cloth. If necessary,
rubbing alcohol may be used to remove any stubborn
dirt.
WARNING
Do not lubricate any of the components of the wheel.
Lubrication may cause the wheel components to fail
GXULQJXVHZKLFKFRXOGUHVXOWLQPRZHUGDPDJHDQGRU
serious personal injury to the operator.
3. Reinstall wheel gear with the arrows facing the front
of the mower. Reinstall pins, washer, e-rings, and dust
cover.
4. Reinstall wheel and nut. Tighten nut to secure.
REPLACING THE WHEELS
6HH¿JXUH
