The isolator key must be inserted before the mower can
be started.
MULCHING PLUG
Your mower is equipped with a mulching plug that covers
the rear discharge opening, which allows the mower blade
to cut and recut for ner clippings.
SELF-PROPELLED FEATURE
Pulling the self propel lever (green) upward to meet the
handle turns on the self-propelled feature of your mower.
SIDE DISCHARGE DEFLECTOR
Use the side discharge deector on your mower when
the grass is too high to mulch or when side discharging
is preferred. The grass clippings produced when using
the side discharge deector are noticeably larger than
those produced when using the mulching plug and side
mulching plate.
SIDE DISCHARGE DOOR
Your mower is equipped with a door that covers the side
discharge opening, which allows the mower blade to cut
and recut the grass for ner clippings if the mulching plug
is engaged, or otherwise sends the grass clippings to the
collection bag.
ASSEMBLY
UNPACKING
This product requires assembly.
■ Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
WARNING
Do not use this product if any parts on the packing list are
already assembled to your product when you unpack it.
Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
■ Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
■ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
■ If any parts are damaged or missing, please call your
Ryobi service centre for assistance.
SPECIFICATIONS
Lawn mower RLM4852L
Width of cut 50.2 cm
Height of cut 19 mm - 76 mm
No-load speed 3000 rpm
Self-propelled speed 0.8~1.0 m/s
Grassbox capacity 55 L
Mower weight 43.1±2 kg
Serial number See product rating label
Battery Lead-acid
Battery number 31108469
Rated voltage 48 V
Charging time 8-10 Hours
Weight 14.6 ± 0.7 kg
Battery charger QL-91435A-4801300F
Input 220-240 V, 50-60 Hz, AC only
Output 48 V DC, 1.3 A
Allowable charging
temperature range
0-40 ˚C
KNOW YOUR LAWN MOWER
See gure 1.
The safe use of the product requires an understanding of
the information on the tool and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all
operating features and safety rules.
BATTERY METER
The battery meter measures the amount of charge
remaining in the battery.
GRASSBOX
The grassbox collects grass clippings and prevents them
from being discharged across your lawn as you mow.
HEIGHT ADJUSTMENT LEVER
The height adjustment lever provides cutting height
adjustments.
MOTOR CONTROL CABLE
The motor control cable, located on the upper handle of
the mower, engages and disengages the motor and blade.
