n Make sure all guards, straps, deflectors and handles
are properly and securely attached.
n Use only the manufacturer's replacement line in the
cutting head. Do not use any other cutting attachment.
n Never operate unit without the safety guard in place
and in good condition.
n Maintain a firm grip on both handles while trimming.
Keep bump head below waist level. Never cut with
the bump head located over 76 cm or more above the
ground.
5
RLT30CDNB RLT30CESNB
Weight (kg)
- Without fuel and trimming head 4.66 5.25
- Without fuel with trimming head 4.80 5.42
Fuel tank volume [cm
3
or (L)] 415 or (0.415) 415 or (0.415)
Cutting swath (mm) 432 432
Engine displacement (cm
3
/
cc) 30 30
Line diameter (Reel Easy
TM
) (mm) 2.4 2.4
Line diameter (Pro Cut II
TM
) (mm) 2.7 2.7
Maximum engine performance
(in accordance with ISO 8893) (kW) 0.75 0.75
Maximum rotational frequency
of the the spindle (min
-
1
) 12,000 12,000
Engine speed (rotational frequency)
at recommended max. spindle
rotational frequency (min
-
1
) 12,000 12,000
Engine speed (rotational frequency)
at idle (min
-
1
) 2,800-3,800 2,800-3,800
Fuel consumption (in accordance
with ISO 8893) at max. engine performance [kg/h or (L/h)] 0.48 or (0.66) 0.48 or (0.66)
Specific fuel consumption
(in accordance with ISO 8893)
at max. engine performance [g/kW.h or (L/kW.h)] 460 or (0.87) 460 or (0.87)
1. Primer Bulb
2. Choke Lever
3. Fuel Cap
4. Starter Grip
5. Throttle Lock
6. On / Off Switch
7. Throttle Trigger
8. Rear Handle
9. Front Handle
10. Shaft
11. Grass Deflector
12. Pro Cut II
TM
13. Cutting Line
14. Idle Speed Screw
15. Reel Easy
TM
(RLT30CESNB)
16. Knob (RLT30CESNB)
17. Hanger Cap (RLT30CESNB)
Please refer to Fig. 2.
Do not attempt to modify this product or create
accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
