SAJ H2-10K-T2 Instruction Manual

Figure 5.2
Expo limit wiring schematic
HYBRID SOLAR INVERTER INSTRUCTION MANUAL
5.4
Working Modes
5.5
Expo Limit Setting
Self-consumption Mode: When the solar is sucient, electricity generated by photovoltaic
system will be supplied to load rst, the surplus energy will be stored in batte, then the excess
electricity will be expoed to the grid. When the solar is insucient, the batte will release
electricity to supply load.
Back-up Mode: Reseed Backup SOC setting value can be adjusted, when batte SOC is less
than reseed SOC value, batte can only be charged, until SOC reaches reseed value, the
batte will be stopped charging; when SOC is larger than SOC setting value, batte will
behave as Self-use mode.
Time-of-use Mode: Batte charging period and discharging period can be set, during
charging period, batte can only be charged, while in discharging period, batte can only be
discharged, the rest of the period, batte will behave as Self-use mode.
3635
5.4.1
Selecting working
modes procedures
5.4.2
Working modes
introduction
5.5.1
APP Setting
Enter the main page of local connection and click on Expo limitation setting, enter the
password “201561”.
