SAJ H2-5K-T2 Instruction Manual

Guangzhou Sanjing Electric Co., Ltd.
SAJ Innovation Park, No.9, Lizhishan Road, Guangzhou Science City, Guangdong,
P.R.China.
Postcode: 510663
Web: http: //www.saj-electric.com
Technical Suppo & Seice
Tel: +86 20 6660 8588
Fax: +86 206660 8589
E-mail: seice@saj-electric.com
International Sales
Tel: 86-20-66608618/66608619/66608588/66600086
Fax: 020-66608589
E-mail: info@saj-electric.com
Domestic Sales
Tel: 020-66600058/66608588
Fax: 020-66608589
8.
Contact SAJ
43 44

SAJ H2-5K-T2 Specifications

General

Number of MPPTs	2
Rated AC Output Power	5000 W
Max. Output Current	22.7 A
Rated AC Voltage	230 V
Rated Grid Frequency	50/60 Hz
THDI	<3%
European Efficiency	97.5%
DC Switch	Yes
Protection Degree	IP65
Cooling Method	Natural Convection
Weight	18 kg
Max. AC Apparent Power	5500VA
Power Factor	>0.99
Operating Temperature Range	-25°C to 60°C
Communication	RS485, WiFi (optional)
Humidity	0-100%
