SAJ PDS33 Series User Manual

PDS33 Series
- 15 -
Controller Model
PDS33-4T022
PDS33-4T030
PDS33-4T037
PDS33-4T045
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-750V
Recommended PV Array Power[kW]
26.4～35.2
36～48
44～59.2
54～72
Alternate AC Generator
Input Voltage
Three Phase AC 380V(±15%)
Max Amps(RMS)[A]
46.5
62
76
92
Power and VA Capability[kVA]
30
40
57
69
Output Data
Output Voltage, Rated
Three Phase AC 380V(±15%)
Max Amps(RMS)[A]
45
60
75
91
Output Power, Rated[kW]
22
30
37
45
Output Frequency
0～50Hz/60Hz
Controller Model
PDS33-4T055
PDS33-4T075
PDS33-4T093
PDS33-4T110
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-750V
Recommended PV Array Power[kW]
66～88
90～120
112～149
132～176
Alternate AC Generator
Input Voltage
Three Phase AC 380V(±15%)
Max Amps(RMS)[A]
113
157
180
214
Power and VA Capability[kVA]
85
114
134
160
Output Data
Output Voltage, Rated
Three Phase AC 380V(±15%)
Max Amps(RMS)[A]
112
150
176
210
Output Power, Rated[kW]
55
75
93
110
Output Frequency
0～50Hz/60Hz
Note: according to different regions, the recommended PV array power is 1.2 ~ 1.6
times the power of the controller.

SAJ PDS33 Series Specifications

General

Brand	SAJ
Model	PDS33 Series
Category	Control Unit
Language	English
