SAJ Sununo Plus Series User Manual

Sununo Plus Series
-29-
seated correctly.
（
6
）
Fasten the lock screws on positive and negative connectors into respondent
insulated enclosure and make them tight.
（
7
）
Connect the positive and cathode connectors into positive and negative DC
input terminals of the inverter, a“click” should be heard or felt when the contact
cable assembly is seated correctly.
1. Connection Port
Figure 5.10 Connect the Inverter
NOTICE
· Before inserting the connector into the DC input terminal of the inverter, please make sure
that the DC switch of the inverter is OFF.
