Samsung Electronics
5-3 Ass'y Control In : B93-05854A
5-5
Parts List
No. Code No. Description Specification Q’ty SN/SNA
1 DB61-02907A CASE-CONTROL IN ABS 1 SA
2 D
B95-01140B TERMINAL BLOCK DAF-3P 1 SNA
3 D
B93-05619B ASSY-PCB IN MAIN VIVACE,9K/12K 1 SA
4 D
B93-06153A CONNECT WIRE-T/B(1) LEAD WIRE 1 SNA
5 D
B61-01639A PLATE-CONTROL IN SGCC-M 1.2 1 SNA
6 D
B61-01097A HOLDER-WIRE CLAMP ABS 1 SA
7 6
001-000929 SCREW PH+,M3,L22 1 SNA
8 6
001-001054 SCREW TH,+M4,L10 3 SNA
9 D
B93-04487A CONNECT WIRE STEP MOTOR 1 SNA
10 DB95-01113A SENSOR 4P(103AT) 1 S
A
11 DB91-00434A ASSY POWER CORE H05VV-F 3*1.0, Core 1 S
NA
12 DB93-04622A CONNECT WIRE DISPLAY 1 S
NA
13 DB93-04430A ASSY MODULE PCB MODULE 1 S
NA
14 DB93-04484A CONNECT WIRE STEP MOTOR, GRILL 1 S
NA
15 DB93-04367A CONNECT WIRE POWER 1 S
NA
16 DB93-04695A CONNECT WIRE MPI ASSY 1 S
NA
17 6001-000725 SCREW-MACHINE TH M4*L16 1 S
NA
To Next Page
