Disassembly and Assembly
28
2 Use a cross-head screwdriver to remove the screw located on the Dummy SSD, and
then pull the Dummy SSD horizontally out of the SSD socket to separate it.
Be careful not to damage the near components.
Check the number of screws that have been removed, and store them carefully
to make sure that no unassembled screws are left inside the computer during
assembly.
2
1
After you finish disassembling, refer to SSD Assembly for how to reassemble.
