Samsung QB75R User Manual

Table of contents
Preparations
Checking the Components 3
Parts 4
Q*32R*/Q*43R*/Q*49R*/Q*50R*/Q*55R*/
Q*65R*/Q*75R*/Q*82R*/Q*85R
* 4
QB98R
5
Anti-theft Lock 6
Ports 7
Q*43R*/Q*49R*/Q*50R*/Q*55R*/Q*65R*/
Q*75R*/Q*82R*/Q*85R
* 7
QM43R-A/QM50R-A/QM55R-A/QM65R-A/
QM75R-A/QM43R-B/QM50R-B/QM55R-B/
QM65R-B/QM75R-B
8
QM32R
9
QM32R-A/QM32R-AN/QM32R-B
10
QB98R
11
QM32R-T
12
QM43R-T/QM55R-T
13
Control menu 14
Administrator menu (Supported models:
QMR-T
) 15
Precautions when handling the panel 16
2
Specifications
General 24
Preset Timing Modes 27
Appendix
Licence 28
Before Installing the Product (Installation
Guide) 17
Tilting Angle and Rotation 17
Ventilation 17
Installing the Wall Mount 18
Preparing before installing Wall-Mount 18
Installing the Wall Mount 18
Wall Mount Kit Specifications (VESA) 19
Using a touchscreen monitor
(Supported models: QMR-T)
Touchscreen monitor 20
Read below before using the product 20
Connecting the touch overlay 20
Connecting the touchscreen monitor 21
Connecting to a PC 21
Connecting to a laptop or tablet PC 21
Configuring the touchscreen monitor
settings 22
Calibration 22

Samsung QB75R Specifications

General

Color gamut	92 %
Pixel pitch	0.42975 x 0.42975 mm
Response time	8 ms
Display diagonal	74.5 \
Display brightness	350 cd/m²
Display technology	LED
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 81 kHz
LED backlighting type	Edge-LED BLU
Contrast ratio (typical)	4000:1
Display number of colors	16.78 million colors
Active display area (W x H)	1650.24 x 928.26 mm
Dynamic contrast ratio marketing name	Mega Contrast
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	11.5 mm
Placement supported	Indoor
Bezel width (bottom)	12.5 mm
Panel mounting interface	400 x 400 mm
Package depth	223 mm
Package width	1871 mm
Package height	1127 mm
Package weight	49000 g
AC input voltage	100 - 240 V
Heat dissipation	787.7 BTU/h
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	150 W
L2 cache	2048 KB
User memory	3.88 GB
Memory clock speed	1500 MHz
VGA (D-Sub) input ports	0
Ethernet LAN (RJ-45) ports	1
Cables included	AC
Purpose	Universal
Operating hours (hours/days)	16/7
Internal memory	2.5 GB
Processor cores	4
Processor model	A72
Processor family	ARM Cortex
Processor frequency	1.7 GHz
Audio formats supported	AC3
Image formats supported	JPEG, PNG
Video formats supported	AVC, AVS, H.263, H.264, HEVC, MPEG1, MPEG2, MPEG4, VC-1, VP8, VP9
Internal storage capacity	8 GB
Operating system installed	Tizen 4.0
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	20 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	49.7 mm
Width	1681.1 mm
Height	960.1 mm
Weight	38300 g
