Samsung QM32R User Manual

14
Control menu
"
The power button(«) is located on the bottom of the product.
"
If you press the power button on the product when the product is
turned on, the control menu will be displayed.
Power off
Source
Press: Move Press & Hold: Select
Items Description
Power off
Power off the product.
• With the control menu screen displayed, briefly press the power button to
move the cursor to
Power off, and then press and hold the power button to
turn off the product.
Source
Select the connected input source.
• With the control menu screen displayed, briefly press the power button to
move the cursor to
Source, and then press and hold the power button to
display the input source screen.
• With the input source screen displayed, press and hold the power button to
switch to the desired input source.
"
The power button can only be used for Power off and Source.
"
To exit from the control menu screen, wait for 3 seconds or more without pressing the power button.

Samsung QM32R Specifications

General

Pixel pitch	0.36 x 0.36 mm
Response time	8 ms
Display diagonal	32 \
Display brightness	400 cd/m²
Display technology	-
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 81 kHz
LED backlighting type	Edge-LED
Contrast ratio (typical)	5000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	80 cm
Dynamic contrast ratio marketing name	Mega Contrast
DVI port	No
USB port	Yes
USB ports quantity	2
HDMI ports quantity	3
VGA (D-Sub) input ports	0
Package depth	120 mm
Package width	812 mm
Package height	512 mm
Package weight	8000 g
Product color	Black
Product design	Digital signage flat panel
Placement supported	Indoor
Bezel width (bottom)	8.8 mm
Panel mounting interface	200 x 200 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Purpose	Universal
Operating system installed	Tizen 4.0
AC input voltage	100 - 240 V
AC input frequency	50 / 60 Hz
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	44 W
Annual energy consumption	64 kWh

Weight and Dimensions

Depth	34.6 mm
Width	725.1 mm
Height	419.6 mm
Weight	5700 g
