Samsung SL600 User Manual

080
PictBridge : Reset
Initializes user-changed configurations.
1. Use the Up / Down button to select the
[Reset] menu tab. And then press the
Right button.
2. Use the Up / Down button to select the
desired sub menu and then press the
OK button.
If [Yes] is selected : All print and image
settings will be reset.
If [No] is selected : Settings will not be reset.
Ä
Default print setting varies depending on the printer manufacturer.
For your printer’s default setting, refer to the user’s guide that came
with your printer.
Important notes
Be sure to observe the following precautions!
å
This unit contains precision electronic components. Do not
use or store this unit in the following locations.
- Areas exposed to severe changes in temperature and humidity.
- Areas exposed to dust and dirt.
- Areas exposed to direct sunlight or the inside of a vehicle in hot
weather.
- Environments where there is high magnetism or excessive vibration.
- Areas with high explosives or highly flammable materials.
å
Do not leave this camera in places subject to dust, chemicals
(like naphthalene and mothballs), high temperature and high
humidity. Keep this camera with silica gel in a hermetically
sealed box when not planning to use the camera for a long
period of time.
å
Sand can be particularly troublesome to cameras.
- Do not let sand get inside the camera when using it on beaches,
coastal dunes, or other areas where there is lots of sand.
- Doing so may result in failure or may permanently render the
camera unusable.
å
Handling the camera
- Never drop the camera or subject it to severe shocks or vibrations.
- Protect the large size LCD monitor from an impact. When this
camera is not used, keep it in the camera case.
- Avoid obstructing the lens or the flash when you capture an image.
- This camera is not waterproof.
To avoid dangerous electrical shocks, never hold or operate the
camera with wet hands.
- If you use this camera in wet places, such as beach or pool, do
not let water or sand get inside the camera. Doing so may result
in failure or may permanently damage the unit.
Back Set
File Name :Auto
Reset No
Date :Auto
Yes
No

Samsung SL600 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Maximum image resolution	4000 x 3000 pixels
Digital zoom	- x
Optical zoom	5 x
Focal length range	4.9 - 24.5 mm
Interface	USB, A/V-out
Digital SLR	No
Power supply type	DC
Aperture range (F-F)	3.5 - 5.9
Camera shutter speed	1/8 - 1/2000 s
Compatible operating systems	-
Focal length (35mm film equivalent)	- mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 - ∞ m
Auto focusing (AF) modes	Centre weighted Auto Focus, Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (wide)	0.05 - 0.8 m
Auto Mode focusing range (tele)	1 - ∞ m
Auto Mode focusing range (wide)	0.05 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, Auto
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash recharging time	4 s
Internal memory	9.9 MB
Compatible memory cards	MMC, SD, SDHC
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Analog signal format system	NTSC, PAL
Display diagonal	2.7 \
Display resolution (numeric)	- pixels
USB version	2.0
Scene modes	Backlight, Beach, Children, Close-up (macro), Dawn, Documents, Fireworks, Night, Night portrait, Portrait, Self-portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Tungsten
Camera playback	movie, single image
Self-timer delay	2 s
Product color	Silver
Battery type	BP-70A
Power requirements	4.2V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Weight	135 g
