Samsung WB250F User Manual

Wireless network 112
Connecting to a WLAN and conguring network settings
Learn to connect via an access point (AP) when you are in a range of a WLAN. You can also congure network settings.
Icon Description
Ad hoc AP
Secured AP
WPS AP
Signal strength
Press [ t ] or touch to open AP setting options
• When you select a secured AP, a pop-up window appears. Enter the required
passwords to connect to the WLAN. For information about entering text, refer
to "Entering text". (p. 115)
• When a login page appears, refer to "Using the login browser". (p. 113)
• When you select an unsecured AP, the camera will connect to the WLAN.
• If you select a WPS prole supported AP, select  WPS PIN connection,
and then enter a PIN on the AP device. You can also connect to a WPS prole
supported AP by selecting
 WPS button connection on the camera, and
then pushing the WPS button on the AP device.
Connecting to a WLAN
1
Rotate the mode dial to w .
2
Select , , , or .
3
Press [ m ], and then select Wi-Fi Setting.
• In some modes, follow the on-screen instructions until the Wi-Fi Setting
screen appears.
• The camera automatically searches for available AP devices.
4
Select an AP.
Refresh
Back
• Select Refresh to refresh connectable APs.
• Select Add wireless network to add an AP manually. Your AP name must be
in English to add the AP manually.

Samsung WB250F Specifications

General

Megapixel	14 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	16.4 MP
Image sensor size	1/2.33 \
Image formats supported	EXIF, JPG
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	1024 x 768, 1920 x 1080, 1984 x 1488, 2592 x 1944, 2832 x 2832, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom	5 x
Optical zoom	18 x
Focal length range	4 - 72 mm
Maximum aperture number	5.8
Minimum aperture number	3.2
Maximum focal length (35mm film equiv)	432 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto/Manual
Normal focusing range	0.8 - ∞/3.5 - ∞ m
Auto focusing (AF) modes	Centre weighted Auto Focus, Multi Point Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1.8 - 3.5 m
Macro focusing range (wide)	0.05 - 0.8 m
Manual focusing range (tele)	1.8 - ∞ m
Manual focusing range (wide)	0.05 - ∞ m
Normal focusing range (tele)	3.5 - ∞ m
Normal focusing range (wide)	0.8 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	16 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 1.51 m
Flash range (wide)	0.3 - 3.38 m
Flash recharging time	4 s
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Audio formats supported	AAC
Memory slots	1
Internal memory	9.5 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
HDMI	No
PictBridge	-
USB version	2.0
Product color	White
Scene modes	Backlight, Fireworks, Night portrait, Portrait, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating, Trimming
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent H, Fluorescent L, Tungsten
Shooting modes	Auto, Manual, Movie, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Sharpness levels	Normal, Soft, Vivid
Camera file system	DCF, DPOF 1.1, Exif 2.21
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery type	SLB-10A
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	21.65 mm
Width	106.05 mm
Height	61.65 mm
Weight	184 g
