Samsung WB31F User Manual

Wireless network 102
Connecting to a WLAN and conguring network settings
Learn to connect via an access point (AP) when you are in a range of a WLAN. You can also congure network settings.
Icon Description
Ad hoc AP
Secured AP
WPS AP
Signal strength
Press [ ] to open network setting options.
• When you select a secured AP, a pop-up window appears. Enter the
required passwords to connect to the WLAN. For information about
entering text, refer to "Entering text". (p. 105)
• When a login page appears, refer to "Using the login browser". (p. 103)
• When you select an unsecured AP, the camera will connect to the WLAN.
• If you select a WPS prole supported AP, select → WPS PIN connection,
and then enter a PIN on the AP device. You can also connect to a WPS
prole supported AP by selecting
→ WPS button connection on the
camera, and then pushing the WPS button on the AP device.
Connecting to a WLAN
1
On the Home screen, scroll to <Wi-Fi>.
2
Select , , , or .
3
Press [ ], and then select Wi-Fi Setting.
• In some modes, follow the on-screen instructions until the Wi-Fi Setting
screen appears.
• The camera automatically searches for available AP devices.
4
Select an AP.
Wi-Fi Setting
Back Manual
Refresh
Samsung 1
Samsung 2
Samsung 3
Samsung 4
• Select Refresh to refresh connectable APs.
• Select Add wireless network to add an AP manually. Your AP name must
be in English to add the AP manually.

Samsung WB31F Specifications

General

Megapixel	16.2 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.3 \
Image formats supported	EXIF, GIF, JPEG XR
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	1024 x 768, 1920 x 1080, 1984 x 1488, 2592 x 1944, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	5 x
Optical zoom	10 x
Focal length range	4.3 - 43 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	240 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 - ∞/2.5 - ∞ m
Auto focusing (AF) modes	Centre weighted Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1.3 - 2.5 m
Macro focusing range (wide)	0.05 - 0.8 m
Normal focusing range (tele)	2.5 - ∞ m
Normal focusing range (wide)	0.8 - ∞ m
Auto Mode focusing range (tele)	1.8 - ∞ m
Auto Mode focusing range (wide)	0.05 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, Auto
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	16 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 1.6 m
Flash range (wide)	0.2 - 3.3 m
Flash recharging time	4 s
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Video formats supported	H.264, MPEG4
Maximum video resolution	1280 x 720 pixels
Audio formats supported	AAC
Memory slots	1
Internal memory	9.5 MB
Compatible memory cards	microSD (TransFlash), microSDHC, microSDXC
Maximum memory card size	64 GB
Display diagonal	3 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	White
Scene modes	Backlight, Beach, Close-up (macro), Fireworks, Night, Portrait, Snow, Sunset, Landscape (scenery)
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent H, Fluorescent L, Tungsten
Self-timer delay	2, 10 s
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery type	BP70A
Battery voltage	3.7 V
Battery capacity	740 mAh
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Bluetooth	No

Weight and Dimensions

Depth	16.5 mm
Width	98 mm
Height	57.9 mm
Weight	131 g
