Sanyo C2462R User Manual

– 22 –
SM830092
7. REFRIGERANT FLOW DIAGRAM
Indoor Unit: KS2462R Outdoor Unit: CL2462R
Indoor Unit: KS2462R Outdoor Unit: C2462R
Condenser
Compressor
Accumulator
Sub-condenser
HP
High
pressure
switch
O. D.
3/4"
(19.05mm)
O. D.
3/4"
(19.05mm)
Wide tube
Narrow tube
O. D.
3/8"
(9.52 mm)
O. D.
3/8"
(9.52 mm)
Evaporator
Narrow tube
service valve
Wide tube
service valve
Indoor Unit Outdoor Unit
HP
High
pressure
switch
LP
LP
Strainer
Capillary
tube
2201_M_S
Evaporator
Condenser
Compressor
Accumulator
Sub-condenser
S
Capillary
HGBV
O. D.
3/4"
(19.05mm)
Wide tube
O. D.
3/4"
(19.05mm)
Narrow tube
O. D.
3/8"
(9.52 mm)
O. D.
3/8"
(9.52 mm)
Strainer
Capillary
tube
Narrow tube
service valve
Wide tube
service valve
Indoor Unit Outdoor Unit
2202_M_S

Sanyo C2462R Specifications

General

Brand	Sanyo
Model	C2462R
Category	Air Conditioner
Language	English
