TC : Total Cooling Capacity (BTU/h)
SHC : Sensible Heat Capacity (BTU/h)
KW : Compressor Input (kW)
Rating conditions (* mark) are: Outdoor ambient temperature 95°F DB
Indoor unit entering air temperature 80°F DB/67°F WB
Rating Capacity: 11,700 BTU/h Air Flow Rate: 360 CFM
Evaporator Condenser
Ent. Temp. °F (°C) Ambient Temp. °F (°C)
WB DB
75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 11,580 11,060 10,530 9,930 9,130
KW 0.89 0.97 1.05 1.14 1.25
59 72 (22.2) SHC 8,690 8,430 8,170 7,880 7,500
(15.0) 76 (24.4) SHC 9,850 9,590 9,340 9,050 8,670
80 (26.7) SHC 11,070 10,810 10,530 9,930 9,130
84 (28.9) SHC 11,580 11,060 10,530 9,930 9,130
88 (31.1) SHC 11,580 11,060 10,530 9,930 9,130
TC 11,980 11,610 11,150 10,540 9,710
KW 0.89 0.98 1.07 1.16 1.28
63 72 (22.2) SHC 7,260 7,090 6,890 6,620 6,260
(17.2) 76 (24.4) SHC 8,430 8,260 8,050 7,780 7,420
80 (26.7) SHC 9,650 9,480 9,270 9,000 8,640
84 (28.9) SHC 10,810 10,640 10,440 10,170 9,710
88 (31.1) SHC 11,980 11,610 11,150 10,540 9,710
TC 12,310 12,110 *11,700 11,060 10,300
KW 0.90 0.99 1.08 1.18 1.31
67 72 (22.2) SHC 5,800 5,720 5,550 5,290 4,980
(19.4) 76 (24.4) SHC 6,960 6,880 6,710 6,450 6,150
80 (26.7) SHC 8,180 8,100 7,930 7,670 7,370
84 (28.9) SHC 9,350 9,260 9,100 8,830 8,530
88 (31.1) SHC 10,510 10,430 10,260 10,000 9,700
TC 12,690 12,480 12,170 11,620 10,940
KW 0.91 1.00 1.10 1.21 1.33
71 72 (22.2) SHC 4,290 4,210 4,090 3,890 3,640
(21.7) 76 (24.4) SHC 5,460 5,380 5,260 5,060 4,810
80 (26.7) SHC 6,670 6,590 6,480 6,270 6,030
84 (28.9) SHC 7,840 7,760 7,640 7,440 7,190
88 (31.1) SHC 9,000 8,930 8,810 8,600 8,360
TC 12,940 12,800 12,520 12,070 11,580
KW 0.93 1.02 1.11 1.24 1.37
75 76 (24.4) SHC 3,960 3,910 3,820 3,670 3,510
(23.9) 80 (26.7) SHC 5,180 5,130 5,030 4,890 4,720
84 (28.9) SHC 6,340 6,290 6,200 6,050 5,890
88 (31.1) SHC 7,510 7,460 7,360 7,220 7,050
4. COOLING CAPACITY
Indoor unit KHS1232
Outdoor unit CH1232
230V single phase 60Hz
