1. Specifications
1-2 Major Component Specifications
(B) Outdoor Unit
+ 2.0
+ 0.5
DATA SUBJECT TO CHANGE WITHOUT NOTICE
MODEL No. CH4242
Source 230 - 208 V / 1 phase / 60 Hz
Compressor Scroll (Hermetic)
Model ZR47KC - PFV
Source 230 - 208 V / 1 phase / 60 Hz
Nominal output W 4,270
Compressor oil cc 1,240
Coil resistance (Ambient temperature 77 °F) Ω R - W : 0.475 , S - W : 1.850
Safety device Internal type
Overload relay models —
Operating temperature Open °F 320 ± 9
Close °F 189 ± 20
Operating ampere (at 77 °F) A —
Run capacitor VAC, µF 400 V, 50 µF
Refrigerant amount charged at shipment lbs. (kg) R22 : 9.7 (4.4)
High pressure switch ACB - 1UB11
Set pressure OFF kg/cm
2
30
ON kg/cm
2
24 ± 2.0
Fan Propeller
Number...diameter in. (mm) 1 … 18-3/32 (460)
Fan speeds 2 (AUTO)
Fan motor
Model KFC6T - 91D6P × 2
Source 230 - 208 V / 1 phase / 60 Hz
No. of pole … rpm (230 V, High) rpm 6 … 879
Nominal output W 110 × 2
Coil resistance Ω BRW – WHT : 67.14 , VLT – YEL : 11.42
(Ambient temperature 68 °F)
WHT – VLT : 64.85 , YEL – PNK : 10.60
Safety device
Operating temperature Open °F248± 9
Close °F171± 27
Run capacitor VAC, µF 440 V, 4 µF × 2
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … Fins per inch 2 … 12.7
Face area ft.
2
(m
2
) 11.63 (1.08)
