PARTS LIST

REF.NO. PART NO. DESCRIPTIONBUTTON-TOP P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

72 614 331 8859 ASSY,PWB,BUTTON-TOP(Only initial)

CN651 614 331 8910 ASSY,WIRE

S6510 645 048 3820 SWITCH,PUSH

S6511 645 048 3820 SWITCH,PUSH

S6512 645 048 3820 SWITCH,PUSH

S6513 645 048 3820 SWITCH,PUSH

S6514 645 048 3820 SWITCH,PUSH

S6515 645 048 3820 SWITCH,PUSH

S6516 645 048 3820 SWITCH,PUSH

S6517 645 048 3820 SWITCH,PUSH

S6524 645 048 3820 SWITCH,PUSH

S6525 645 048 3820 SWITCH,PUSH

S6526 645 048 3820 SWITCH,PUSH

S6527 645 048 3820 SWITCH,PUSH

FRONT & CD P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

73 614 332 6519 ASSY,PWB,FRONT-CD(Only initial)

AH601 614 330 7358 HOLDER,LCD

AS601 614 330 7334 DEC,SHEET LCD

CN111 645 059 0498 SOCKET,FPC 16P

CN112 645 005 8127 PLUG,6P

CN122 645 005 8141 PLUG,9P

or 614 310 2502 PLUG,9P

CN145 645 012 6369 JACK,RCA-2

CN146 645 005 7373 PLUG,3P

CN601 645 009 4163 SOCKET,FFC 12P

CN602 645 009 4163 SOCKET,FFC 12P

CN604 645 005 8110 PLUG,4P

CN605 645 005 8141 PLUG,9P

CN606 645 005 7366 PLUG,2P

CN610 645 005 7373 PLUG,3P

CN611 645 005 7366 PLUG,2P

CN612 645 005 7373 PLUG,3P

D1501 407 098 3300 DIODE RL153-BF-S2

D1502 407 098 3300 DIODE RL153-BF-S2

D6010 407 012 4406 DIODE 1SS133

D6110 407 012 4406 DIODE 1SS133

D6111 407 012 4406 DIODE 1SS133

D6113 407 012 4406 DIODE 1SS133

D6201 407 099 4603 ZENER DIODE MTZJ3.9B

D6406 407 099 5204 ZENER DIODE MTZJ5.1B

D6960 407 012 4406 DIODE 1SS133

IC101 410 538 0401 IC LC78646E-UHK-E

IC102 410 538 0500 IC LC78684NE-UHK-E

IC103 410 530 7804 IC M12L16161A-7TG

IC104 409 582 6002 IC LA6548NH-E

IC601 410 547 9303 IC LC877464C-54P5-E

JW200 614 332 4034 ASSY,WIRE

L1301 645 002 1459 INDUCTOR,22U K

L1302 645 037 2858 CORE,PIPE

L1303 645 001 4581 INDUCTOR,100U K

L1304 645 001 5519 INDUCTOR,47U K

L1305 645 001 5519 INDUCTOR,47U K

L1306 645 001 5519 INDUCTOR,47U K

L1401 645 037 2858 CORE,PIPE

L1501 645 037 2858 CORE,PIPE

L6010 645 001 5441 INDUCTOR,2.2U K

LCD60 645 071 1107 LCD

PR151 645 066 9668 PROTECTOR,0.4A 125V

Q1301 405 008 7301 TR 2SB810-F

or 405 008 7202 TR 2SB810-E

or 405 008 6809 TR 2SB808-F-SPA

Q1401 405 017 9709 TR 2SC3330-U

or 405 011 8609 TR 2SC1740S-S

or 405 011 8500 TR 2SC1740S-R

or 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

Q1501 405 009 5306 TR 2SB927-T

or 405 009 5207 TR 2SB927-S

or 405 141 3604 TR KTA1273-Y

LED P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

74 614 332 6540 ASSY,PWB,LED(Only initial)

CN680 614 331 8934 ASSY,WIRE

D6803 407 244 9705 LED LT5CB1-81-UAC3,VOL BLUE

TUNER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

75 614 332 0975 ASSY,PWB,TUNER(Only initial)

C2457 403 259 0508 NP-ELECT 1U M 50V

CN201 645 057 1909 TERMINAL,TUNER

CN202 645 004 2683 PLUG,2P

CN205 645 009 4163 SOCKET,FFC 12P

CN206 645 005 8110 PLUG,4P

CT252 645 032 5663 TRIMMER,7PF

D2103 407 149 0807 DIODE 1SS355

D2104 407 149 0807 DIODE 1SS355

D2151 407 012 4406 DIODE 1SS133

D2152 407 149 0807 DIODE 1SS355

D2153 407 105 1602 VARACTOR DI SVC342M-V

or 407 105 1305 VARACTOR DI SVC342L-V

D2451 407 012 4406 DIODE 1SS133

D2452 407 153 7502 ZENER DIODE GZS3.0B

D2453 407 012 4406 DIODE 1SS133

D2454 407 012 4406 DIODE 1SS133

D2456 407 012 4406 DIODE 1SS133

D2466 407 012 4406 DIODE 1SS133

IC231 409 474 3201 IC LA1844ML

IC241 409 439 4502 IC LC72121M-D

IC251 409 433 2702 IC LC72723M

L2151 645 037 2377 TRANS,ANT,796KHZ

L2153 645 065 3568 TRANS,OSC,796KHZ

L2451 645 031 7842 INDUCTOR,100U K

or 645 001 4581 INDUCTOR,100U K

L2501 645 031 7842 INDUCTOR,100U K

or 645 001 4581 INDUCTOR,100U K

L2502 645 031 7842 INDUCTOR,100U K

or 645 001 4581 INDUCTOR,100U K

Q2140 405 014 4509 TR 2SC2412K-R

or 405 011 1006 TR 2SC1623-L6

or 405 146 2107 TR KTC3875-Y

or 405 146 2206 TR KTC3875-GR

Q2201 405 016 0806 TR 2SC2839-E

or 405 151 4103 TR KTC3193-Y

or 405 151 4202 TR KTC3193-O

Q2310 405 011 8500 TR 2SC1740S-R

or 405 143 8706 TR KTC3199-GR

or 405 011 8609 TR 2SC1740S-S

or 405 017 9600 TR 2SC3330-T

Q6107 405 014 4509 TR 2SC2412K-R

or 405 011 1006 TR 2SC1623-L6

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

Q6108 405 014 4509 TR 2SC2412K-R

or 405 011 1006 TR 2SC1623-L6

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

Q6201 405 005 5508 TR 2SA812-M6

or 405 002 0308 TR 2SA1037K-R

or 405 134 5905 TR 2SA1037AK-R

or 405 146 9700 TR KTA1504-GR

Q6410 405 155 0002 TR MPSA56

Q6960 405 155 0002 TR MPSA56

Q6961 405 155 0002 TR MPSA56

Q6962 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q6963 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

X1451 645 020 9024 OSC,CRYSTAL 16.9344MHZ

X6101 645 032 1627 OSC,CRYSTAL 32.768KHZ

X6102 645 072 1106 OSC,CERAMIC 10.0MHZ
