- 6 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION

AMPLIFIER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

76 614 332 1149 ASSY,PWB,AMP(Only initial)

C4601 403 057 3503 POLYESTER 0.1U K 50V

C4605 403 061 3605 POLYESTER 0.039U J 50V

C4606 403 061 7702 POLYESTER 4700P J 50V

C4607 403 059 3204 POLYESTER 2200P J 50V

C4608 403 060 2807 POLYESTER 0.027U K 50V

C4743 403 057 3503 POLYESTER 0.1U K 50V

C4843 403 057 3503 POLYESTER 0.1U K 50V

C4950 403 332 7400 ELECT 2200U M 50V

C4984 403 329 3309 ELECT 2200U M 25V

CN428 645 006 1806 PLUG,3P

or 614 319 3456 PLUG,3P

CN440 645 005 8127 PLUG,6P

CN441 645 005 7373 PLUG,3P

CN442 614 310 2441 PLUG,3P

or 645 005 7373 PLUG,3P

CN444 645 005 8141 PLUG,9P

CN446 645 009 4163 SOCKET,FFC 12P

CN455 645 011 6384 JACK,PHONE D3.6,HEADPHONE

or 645 055 1017 JACK,PHONE D3.6,HEADPHONE

CN457 645 024 1147 TERMINAL,SPEAKER

D4280 407 196 5800 DIODE 1N5402BD82

D4281 407 196 5800 DIODE 1N5402BD82

D4282 407 196 5800 DIODE 1N5402BD82

D4283 407 196 5800 DIODE 1N5402BD82

D4284 407 196 5800 DIODE 1N5402BD82

D4991 407 099 6805 ZENER DIODE MTZJ13B

D4992 407 099 6003 ZENER DIODE MTZJ9.1B

D4993 407 148 6701 DIODE 1A3-I

D4994 407 098 3300 DIODE RL153-BF-S2

D4995 407 098 3300 DIODE RL153-BF-S2

D4996 407 012 4406 DIODE 1SS133

D4997 407 148 6701 DIODE 1A3-I

D4998 407 012 4406 DIODE 1SS133

HS401 614 330 7341 HEAT SINK

IC440 409 451 7406 IC AN7348K

IC441 409 614 0701 IC LC75348M-E

IC442 409 451 2104 IC TDA7269

IC443 409 189 3404 IC BA7755A

IC446 409 463 6701 IC KIA7805API

L4600 645 006 1523 INDUCTOR,470U J

L4601 645 006 1523 INDUCTOR,470U J

L4602 645 037 2858 CORE,PIPE

L4603 645 006 1523 INDUCTOR,470U J

L4604 645 037 2858 CORE,PIPE

L4605 645 001 5519 INDUCTOR,47U K

L4606 645 001 5519 INDUCTOR,47U K

L4607 645 001 5519 INDUCTOR,47U K

PR420 645 066 9835 PROTECTOR,4A 125V

PR495 645 066 9705 PROTECTOR,0.8A 125V

POWER TRANSFORMER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

77 614 332 0982 ASSY,PWB,POWER,TRANS

(Only initial)

C4108 403 349 3303 CERAMIC 0.01U M 250V

or 403 366 7803 CERAMIC 0.01U M 250V

CN401 645 006 4760 HOLDER,FUSE

or 645 031 7903 HOLDER,FUSE

CN402 645 006 4760 HOLDER,FUSE

or 645 031 7903 HOLDER,FUSE

CN403 614 017 8203 TERMINAL BOARD

CN404 614 017 8203 TERMINAL BOARD

CN410 645 005 9315 PLUG,2P

CN413 614 310 2441 PLUG,3P

or 645 005 7373 PLUG,3P

D4101 407 097 8009 DIODE MPG06G

D4102 407 097 8009 DIODE MPG06G

or 405 017 9709 TR 2SC3330-U

Q2451 405 078 2404 TR BN1A4P

or 405 036 3702 TR 2SA1564

or 405 151 5209 TR KRA107M

or 405 000 0904 TR DTA114YS

S2001 645 023 5795 SWITCH,LEVER

T2002 645 046 2023 FILTER,450KHZ

U2101 645 043 6697 TUNER,FM

X2451 645 023 4965 OSC,CRYSTAL 7.2MHZ

X2501 645 035 8326 OSC,CRYSTAL 4.332MHZ

XF221 645 054 1223 CERAMIC FILTER 10.70MHZ

or 645 010 7665 CERAMIC FILTER 10.70MHZ

or 614 240 2917 FILTER,CERAM

XF222 645 054 1223 CERAMIC FILTER 10.70MHZ

or 645 010 7665 CERAMIC FILTER 10.70MHZ

or 614 240 2917 FILTER,CERAM

XF231 645 059 0054 CERAMIC FILTER 450KHZ

or 645 041 9324 CERAMIC FILTER 450KHZ

XF233 645 040 9981 TRANS,IF 10.7MHZ

or 645 039 9923 TRANS,IF 10.7MHZ

PR496 645 066 9767 PROTECTOR,1.25A 125V

Q4320 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4321 405 004 5004 TR 2SA608-G-NP

or 405 004 4502 TR 2SA608-F-NP

or 405 141 3505 TR KTA1266-Y

or 405 141 3406 TR KTA1266-GR

Q4501 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

Q4502 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

Q4503 405 159 0503 TR KRC107S

or 405 141 5608 TR DTC114YKA

Q4600 405 155 0002 TR MPSA56

Q4601 405 000 3806 TR DTC114YS

or 405 143 0007 TR KRC107M

Q4602 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

Q4603 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 3804 TR 2SC536-G-NP

or 405 019 2708 TR 2SC536-F-NP

Q4700 405 075 8607 TR DTC143ZS

or 405 143 9000 TR KRC106M

Q4800 405 075 8607 TR DTC143ZS

or 405 143 9000 TR KRC106M

Q4990 405 138 6403 TR KTD2058Y

or 405 095 1602 TR 2SD2061-E

or 405 095 1701 TR 2SD2061-F

Q4991 405 095 1701 TR 2SD2061-F

or 405 095 1602 TR 2SD2061-E

or 405 138 6403 TR KTD2058Y

Q4992 405 008 2504 TR 2SB698-G

or 405 008 2405 TR 2SB698-F

or 405 141 3703 TR KTA1271-Y

Q4993 405 008 2504 TR 2SB698-G

or 405 008 2405 TR 2SB698-F

or 405 141 3703 TR KTA1271-Y

Q4994 405 143 0007 TR KRC107M

or 405 000 3806 TR DTC114YS

R4743 402 071 1304 FUSIBLE RES 2.2 JA 1/4W

R4843 402 071 1304 FUSIBLE RES 2.2 JA 1/4W

SA401 411 021 3503 SCR S-TPG BIN 3X10

SA402 411 021 3503 SCR S-TPG BIN 3X10

SA403 411 021 3503 SCR S-TPG BIN 3X10

SA404 411 021 5705 SCR S-TPG BIN 3X6

SA405 411 021 5705 SCR S-TPG BIN 3X6

SA406 411 021 5705 SCR S-TPG BIN 3X6

SH101 614 331 1294 SHIELD,MAIN PWB

SH102 614 331 1300 SHIELD,TERMINAL
