— 14 —
CHASSIS ELECTRICAL PARTS LIST
CAUTION: To Protect against electrical shock and for continued product safety, refer to SAFETY PRECAUTIONS,
X-RADIATION PRECAUTIONS, HIGH VOLTAGE HOLD-DOWN TEST, and PRODUCT SAFETY NOTICE on Page 2.
Notes: Parts having Location Number are located on the following boards.
Numbers under 700 Series . . . . . . . . . . . . . . . . . . . . .On the Main Board.
Numbers 700 Series . . . . . . . . . . . . . . . . . . . . . . . . . . .On the Picture Tube Socket Board.
Numbers 900 Series . . . . . . . . . . . . . . . . . . . . . . . . . . .Out of Board.
All Other Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . .On the Main Board
PRODUCT SAFETY NOTICE
PRODUCT SAFETY SHOULD BE CONSIDERED WHEN A REPLACEMENT IS MADE IN ANY AREA OF A RECEIVER.
COMPONENTS INDICATED BY A STAR (★) IN THIS PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE
COMPONENTS IN WHICH SAFETY CAN BE OF SPECIAL SIGNIFICANCE. IT IS PARTICULARLY RECOMMENDED
THAT ONLY PARTS DESIGNATED ON THE FOLLOWING PARTS LIST BE USED FOR COMPONENT REPLACEMENT
DESIGNATED BY A STAR. NO DEVIATIONS FROM RESISTANCE,WATTAGE,AND VOLTAGE RATINGS MAY BE MADE
FOR REPLACEMENT ITEMS DESIGNATED BY A STAR.
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
Note: Schematic part location numbers may not always match with the part descriptions.
The part descriptions are correct and should be used.
CAPACITORS
NOTES:
Read description of the Capacitor as follows:
(Example)
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
less than 10PF
A . .Not specified
B . .±0.1PF C . .±0.25PF
D . .±0.5PF F . .±1PF
G . .±2PF R . .+0.25 - 0PF
S . .+0 - 0.25PF E . .+0 - 1PF
more than 10PF
A . .Not specified
B . .±0.1% C . .±0.25%
D . .±0.5% F . .±1%
G . .±2% H . .±3%
J . .±5% K . .±10%
L . .±15% M . .±20%
N . .±30% P . .+100 - 0%
Q . .+30 - 10% T . .+50 - 10%
U . .+75 - 10% V . .+20 - 10%
W .+100 - 10% X . .+40 - 20%
Y . .+150 - 10% Z . .+80 - 20%
Rated Value: P...Pico Farad U...Micro Farad
Material:
CERAMIC . . . . . .Ceramic
MT-PAPER . . . . .Metalized Paper
POLYESTER . . .Polyester
MT-POLYEST . .Metalized Polyester
POLYPRO . . . . .Polypropylene
MT-POLYPRO . .Metalized Polypropylene
COMPO-FILM . .Composite Film
MT-COMPO . . . .Metalized Composite
STYRENE . . . . . .Styrene
TA-SOLID . . . . .Tantalum Solid
AL-SOLID . . . . . .Aluminum Solid
ELECT . . . . . . . .Electrolytic
NP-ELECT . . . . .Non-Polarized Electrolytic
OS-SOLID . . . . .Aluminum Solid with Organic
Semiconductive Electrolytic
C001 404 087 2801 ELECT 0.22 M 50V
C002 404 087 2801 ELECT 0.22 M 50V
C003 403 235 5701 CERAMIC 5600P K 50V
C004 403 235 5701 CERAMIC 5600P K 50V
C006 403 224 6108 CERAMIC 0.01U K 50V
C010 404 087 2306 ELECT 220U M 25V
C011 404 087 2306 ELECT 220U M 25V
C012 404 088 5702 ELECT 22U M 16V
C015 404 084 3108 ELECT 330U M 16V
C101 404 084 2408 ELECT 470U M 6.3V
C103 403 224 6108 CERAMIC 0.01U K 50V
C106 404 084 4006 ELECT 2.2U M 50V
C131 404 084 3801 ELECT 1U M 50V
C133 403 224 6108 CERAMIC 0.01U K 50V
C134 403 224 5705 CERAMIC 1000P K 50V
C136 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
C137 403 364 7508 CERAMIC 10P J 50V
C141 403 224 6108 CERAMIC 0.01U K 50V
C142 403 343 4603 CERAMIC 0.022U K 50V
C143 403 224 6108 CERAMIC 0.01U K 50V
C146 403 224 6108 CERAMIC 0.01U K 50V
C147 404 084 2200 ELECT 100U M 6.3V
C151 404 084 3702 ELECT 0 .47U M 50V
C153 404 084 3702 ELECT 0 .47U M 50V
C161 403 357 9601 CERAMIC 0.1U Z 50V
C211 404 084 6901 NP-ELECT 1U M 50V
C212 404 084 4006 ELECT 2.2U M 50V
C221 404 084 6901 NP-ELECT 1U M 50V
C251 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
C252 404 086 6602 POLYESTER 0.047U K 63V
C253 404 084 3702 ELECT 0.47U M 50V
C256 404 084 3801 ELECT 1U M 50V
C257 403 224 6108 CERAMIC 0.01U K 50V
C258 404 084 3207 ELECT 47U M 16V
C272 404 084 4105 ELECT 3.3U M 50V
C274 404 084 2705 ELECT 10U M 16V
C284 404 084 3207 ELECT 47U M 16V
