- 8 -
C0204 403 135 4507 ELECT 1000U M 10V
C0205 403 125 5507 ELECT 1000U M 16V
CN102 645 064 0315 4P CONNECTOR,CON102
CN201 645 067 9377 11P FLAT CABLE AWG26,
CON201 TO MAIN CN511
D0102 645 063 2228 DIODE 1N4007
D0103 645 063 2228 DIODE 1N4007
D0104 645 063 2228 DIODE 1N4007
D0105 645 063 9937 DIODE UF4007
D0107 645 063 9920 DIODE FR103
D0201 645 063 9920 DIODE FR103
D0202 645 064 0445 DIODE 1N5822
D0204 645 063 9944 RECITIFER 1N5819
D0205 645 063 9920 DIODE FR103
F0001
!
!!
645 064 0728 FUSE
IC101 645 064 0452 IC KA5M02659RN,POWRE SWITCH
IC102 645 067 9414 IC SFH615A-3,OPT SENSOR
IC201 645 067 9391 IC TL431 TO-92,VOLT. REGULATOR
L0202 645 064 0483 COIL 10UH
L0203 645 064 0483 COIL 10UH
L0204 645 064 0483 COIL 10UH
R0002 645 066 7725 RESISTOR 1 OHM 1/4W
T0101 645 064 0421 AC FILTER 25MH
645 064 0353 FUSE CLIP,FOR F1
CONTROL P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
19 614 330 3060 ASSY,PWB,CONTROL(Only Initial)
LD501 645 067 9292 LED,LED501
LD502 645 067 9308 LED,LED502
LD503 645 067 9315 LED,LED503
Q0501 645 060 4829 TR 2SC945P,NPN
Q0502 645 060 4829 TR 2SC945P,NPN
Q0503 645 060 4829 TR 2SC945P,NPN
Q57CE 401 105 7909 MT-GLAZE 0.000 ZA 1/16W,Q507 C-E
SN501 645 067 9407 REMOTE RECEIVER,IRT SENSOR
T507A 645 060 4874 SW TACT,TA507A OPEN. CLOSE
T508A 645 060 4874 SW TACT,TA508A POWER
T509A 645 060 4874 SW TACT,TA509A PLAY
TA501 645 060 4874 SW TACT,STOP
TA502 645 060 4874 SW TACT,SKIP UP
TA505 645 060 4874 SW TACT,SKIP DOWM
645 067 9841 EVA SPONGE
645 067 9537 LED HOLDER,FOR LED502 LED503
REF.NO. PART NO. DESCRIPTION
PARTS LIST
