Sanyo PLV-Z3000 Owner's Manual

3
TRADEMARKS
● Each name of corporations or products in this owner’s manual is either a trademark or a registered trademark of its
respective corporation.
Table of Contents
Features and Design................ 2
Table of Contents .................. 3
To the Owner ..................... 4
Safety Instructions ................. 5
Air Circulation 6
Moving the Projector 6
Installing the Projector in Proper Position 6
Compliance ....................... 7
Part Names and Functions........... 8
Front 8
Back 8
Bottom 8
Rear Terminal 9
Top Control 10
Remote Control 11
Remote Control Operating Range 12
Remote Control Battery Installation 12
Installation ...................... 13
Positioning the Projector 13
Adjustable Feet 13
Moving the Lens 14
Connecting to Video Equipment (Video, S-Video) 15
Connecting to Video Equipment (Component) 15
Connecting to Video Equipment (HDMI, RGB Scart) 16
Connecting to a Computer 16
Connecting the AC Power Cord 17
Basic Operation .................. 18
Turning On the Projector 18
Turning Off the Projector 19
How to Operate the On-Screen Menu 20
Menu and its Functions 21
Zoom and Focus Adjustment 22
Remote Control Operation 22
Input............................ 24
Input Source and System Selection 24
Image........................... 27
Image Mode Selection 27
Image Adjustment ................ 28
Image Mode Adjustment 28
Picture Adjustment................ 34
Picture Position and Screen Adjustment 34
Screen .......................... 35
Screen Size Adjustment 35
Setting .......................... 37
Setting 37
Information ...................... 43
Input Source Information Display 43
Maintenance and Cleaning ......... 44
Warning Indicator 44
Cleaning the RGB panels 45
Cleaning the Air Filter 47
Resetting the Filter Counter 48
Cleaning the Projection Lens 48
Cleaning the Projector Cabinet 48
Lamp Replacement 49
Resetting the Lamp Replacement Counter 50
Appendix ........................ 51
Troubleshooting 51
Indicators and Projector Condition 53
Menu Tree 54
System Mode Chart 56
Technical Specifications 57
Configurations of Terminals 58
Optional Parts 58
Dimensions 59

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
