Sanyo PLV-Z3000 Service Manual

Electrical Parts List
ME4-Z300000
- 111 -
610 341 6113 ASSY,PWB,R/C.ME4A
CAPACITOR
C2801 303 282 5118 CERAMIC 470P K 50V
C2802 303 433 1112 CERAMIC 1U K 10V
C2803 303 397 5713 ELECT 100U M 10V
RESISTOR
R2801 301 224 8814 MT-GLAZE 100 JA 1/16W
R2802 301 225 1814 MT-GLAZE 47 JA 1/16W
COIL
L2801 945 086 6662 IMPEDANCE,600 OHM P
MISCELLANEOUS
A2801 645 097 6674 UNIT,REMOCON RECEIVER
610 341 6120 ASSY,PWB,FILTER NET.ME4A
This ass'y has PWB and Plugs only.
Key. No. Part No. Description Key. No. Part No. Description

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
