Sanyo PLV-Z3000 Service Manual

- 78 -
FN901 FN902 FN903 FN904 FN905
1 2
IC301
SYSTEM
CONTROL
IC4401
COLOR
MANAGER
MAIN BOARD
Power-On : H
IC4801
SUB CPU
437
176
65
66
177
FAN3
FAN4
FAN5
FAN2
FAN1
IC8841
TEMP.
SENSOR
K78E
1 2
K78D
1 2
K78C
1 2
K78B
1 2
K78A
FAN_SW
FAN_SW FAN_CTL3
FAN_CTL2
FAN_CTL1
FAN_CTL0
Q7821
Q7831
IC7801
IC7802
IC7861
Q7841
Q7851
IC7891
IC7891 IC7891 IC7891
IC7891
FAN_MTR1-5
FAN_MTR1
FAN_MTR2
FAN_MTR3
FAN_MTR4
FAN_MTR5
FAN1
FAN2
FAN3
FAN4
K8E
K8F 291
343
292
344
293
FAN_CTL0
FAN_CTL1
FAN_CTL2
FAN_CTL3
S16VF
68
439
281
THERM2
THERM_DET
THERM1
TH901
TH902
31 3 31
FAN_SW
● Fan control circuit
FAN(FN905)
FAN(FN904)
FAN(FN902)
FAN(FN903)
FAN(FN901)
TEMP. SENSOR IC(IC8841)_SIDE-B
THERMISTOR(TH902)
FRONT
● Fan and sensor location
Chassis Block Diagrams
THERMISTOR(TH901)
MAIN BOARD

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
