- 42 -
OPTICAL FILTER (R) CONDENSER LENS (G, B)
DICHROIC MIRROR
PBS
Film attached side comes
this side.
Chamfer corner comes
this side.
Chamfer corner comes this side up.
Chamfer corner comes
this side up.
Flat surface side comes
this side.
OPTICAL FILTER
POLARIZED GLASS (IN)
Film attached side comes
this side.
Film attached side
comes this side.
The marker comes this
up side.
The marker comes this
up side.
Optical disassemblies
