1-3. Other Component Specifi cations
Wall-Mounted Type SPW-KR124 – 254GH56 (A/B)
MODEL No.
Indoor Unit SPW-KR124 – 254GH56 (A/B)
Power Transformer
ATR-IIK245
Rated
Source VAC, Hz AC 230 V , 50/60 Hz
Secondary
S1: 11 V, 1.25 A S2: 14 V, 0.45 A
S3: 20 V, 0.2 A
Coil resistance
Ω
Thermal cut off temperature °C 150°C
Thermistor (Coil sensor): TH
PBC-41E-AS7-1, PBC-41E-AS7-3
Resistance
kΩ
–10°C: 23.7±5% 20°C: 6.5±5%
–5°C: 18.8±5% 30°C: 4.4±5%
0°C: 15.0±5% 40°C: 3.1±5%
5°C: 12.1±5% 45°C: 2.6±5%
10°C: 9.7±5% 50°C: 2.1±5%
Thermistor (Coil sensor):
KTEC-35-S
Resistance
kΩ
0°C: 16.5±5% 40°C: 2.7±5%
5°C: 12.8±5% 45°C: 2.2±5%
10°C: 10.0±5% 50°C: 1.8±5%
20°C: 6.3±5% 55°C: 1.5±5%
30°C: 4.0±5%
Electronic expansion valve
Valve body –
Coil –
Drain pump
–
Rated
–
Float switch
–
Rated (Contact rated)
–
SM830160-03ClassicPAC-iA4.ind264264SM830160-03ClassicPAC-iA4.ind264264 2010/02/1610:26:362010/02/1610:26:36
