international 11
Legend, Fig. 1
Get to know your compressor:
1 Handle
2 Pressure switch cover
3 ON/OFF switch
4 Pressure gauge for working pressure
5 Pressure regulator
6 Quick-disconnect coupling for adjustable pressure
6a Quick-disconnect coupling for unreduced pressure
7 Pressure gauge for boiler pressure
8 Pressure relief valve
9 Non-return valve
10 Drain plug
11 Boiler
12 Wheel (2x)
13 Thermo overload switch
14 Sealing plug
15 Air lter unit
16 Oil drain screw with oil-level indicator
m General safety notes
Preserve these Operating Instructions well and have
them carefully read by every person working with the
compressor.
Important information
Attentively read these Operating Instructions. Most of
the accidents when working with the compressor occur
through neglect of the basic safety rules. Recognizing po-
tential dangers in time and conscientious observance of
the safety instructions can avoid accidents. Only use the
compressor following the recommendations of the manu-
facturer.
m Safety notes
• Do not touch moving machine parts.
• Do not use the compressor with the guards removed.
• Always wear goggles or another adequate eye protec-
tion. Never point the compressed air current towards a
part of your body or towards another person.
• Protection from electric shocks. Avoid inadvertent
contact with the cables, the tank, or earthed metal parts
of the compressor. Never use the compressor close to
water or in a humid environment.
• Pull the power supply plug before starting repair, in-
spection, maintenance, or cleaning work, or before re-
placing any parts.
• Inadvertent starting. Do not transport the compres-
sor while it is connected to the electric power. Make
sure the switch is in OFF position before you plug in
the electric cable.
• Store the compressor correctly. When the compres-
sor is not used, it must be stored in a dry place pro-
tected from weather conditions.
• Working area. Make sure the work place is clean and
well aerated. Put away any tools that are not needed.
