www.scheppach.com
26
|
GB
• Avoid accidental starts of the machine: Do not press
the start button while inserting the plug into the
socket.
• Use the tools recommended in this manual to obtain
the best results from your machine.
• Always keep hands away from the work area when
the machine is running.
7. Technical data
Dimensions L x W x H 995 x 425 x 610 mm
Wood ø min. - max. 50 - 250 mm
Wood length min. - max 130 - 370 mm
Weight 45 kg
Motor 230/50 V/Hz
Input P1 1500 W
Output P2 1100 W
Rating S3 25%
Splitting Power max. 4 t
Cylinder rise 290 mm
Cylinder speed (fast fwd.) 3.86 cm/sec
Cylinder speed (return) 6.44 cm/sec
Hydraulic uid capacity 2,4 l
Operating pressure 165 bar
Motor speed 2850 rpm
Subject to technical changes!
*S3, periodic intermittent operation without inuence
of the starting process on the motor heating. Identical
duty cycles with a period at load followed by a period
at no load. Running time 10 minutes; duty cycle is 25%
of the running time.
Noise and vibration
Sound pressure level L
pA
89.8 dB
Uncertainty K
pA
3 dB
Sound power level L
WA
96 dB
Uncertainty K
WA
3 dB
m WARNING: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
• When splitting, the properties of the wood (e.g.
growths, trunk slices of irregular shape, etc.) can re-
sult in hazards such as ejecting parts, splitter block-
ing, and crushing.
6. Additional safety instructions
• The log splitter may only be operated by one per-
son.
• Never split logs containing nails, wire, or other for-
eign objects.
• Already split wood and wood chips can be danger-
ous. You can stumble, slip or fall down. Keep the
working area tidy.
• While the machine is switched on, never put your
hands on moving parts of the machine.
• Only split logs with a maximum length of 37 cm.
m WARNING! This electric tool generates an electro-
magnetic eld during operation. This eld can impair
active or passive medical implants under certain con-
ditions. In order to prevent the risk of serious or dead-
ly injuries, we recommend that persons with medical
implants consult with their physician and the manufac-
turer of the medical implant prior to operating the elec-
tric tool.
Remaining hazards
The machine has been built using modern technology
in accordance with recognized safety rules. Some re-
maining hazards, however, may still exist.
• The splitting tool can cause injuries to ngers and
hands if the wood is incorrectly guided or support-
ed.
• Thrown pieces can lead to injury if the work piece is
not correctly placed or held.
• Injury through electric current if incorrect electric
connection leads are used.
• Even when all safety measures are taken, some re-
maining hazards which are not yet evident may still
be present.
• Remaining hazards can be minimized by following
the safety instructions as well as the instructions in
the chapter Authorized use and in the entire oper-
ating manual.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Release the handle button and switch o the ma-
chine prior to any operations.
