www.scheppach.com / service@scheppach.com / +(49)-08223-4002-99 / +(49)-08223-4002-58
GB
|
25
• Residual risks can be minimised if the “safety in-
structions” and the “Proper use” are observed
along with the whole of the operating instructions.
• Do not unnecessary stress the machine: too much
pressure when drilling will damage the drill quickly.
This results in reduced output of the machine in the
processing and in cut precision.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual. In
doing so, your drill provides optimal performance.
• Keep your hands away from the work area, when
the machine is in operation.
-
chine and unplug the power plug.
6. Technical data
Rated input voltage 230-240V~ 50Hz
Nominal power 550 W
Motor speed 1450 min
-1
Output speed (continuously
440 - 2580 min
-1
Chuck adapter B16
Drilling spindle cone MT2
Chuck 1 - 16 mm
Drilling table size 240 x 240 mm
Angle adjustment 45° - 0° - 45°
Drilling depth 80 mm
Column diameter 65 mm
Height 713 mm
Weight 38,5 kg
Laser class 2
Laser wavelength 650 mm
Power of laser 1mW
Noise and vibration
The noise levels have been determined in accord-
ance with EN 61029.
Sound pressure level Idle L
pA
Sound pressure level L
pA
Uncertainty K
pA
Sound power level Idle L
WA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
Excessive noise can result in a loss of hearing. To-
determined according to EN 61029.
• Regularly inspect the cable and have a dam-
aged cable repaired only by an authorised ser-
vice centre. Replace damaged extension ca-
bles. This ensures that safety of the electric tool
is maintained.
• Securely store unused power tools. The stor-
age space must be dry and lockable. This pre-
vents the power tool from being damaged by stor-
age or being used by inexperienced people.
• Never leave the power tool before it has com-
pletely stopped. Continuously running tools can
cause injuries.
• Do not use the power tool with damaged ca-
bles. Do not touch the damaged cable and pull
the mains plug if the cable gets damaged while
working. Damaged cables increase the risk of an
electric shock.
Attention: Laser beam
Do not look into the beam
Laser class 2
Protect yourself and you environment from ac-
cidents using suitable precautionary measures!
• Do not look directly into the laser beam with un-
protected eyes.
• Never look into the path of the beam.
• -
faces and persons or animals. Even a laser beam
with a low output can cause damage to the eyes.
•
can result in dangerous radiation exposure.
• Never open the laser module. Unexpected expo-
sure to the beam can occur.
• If the product is not used for an extended period of
time, the batteries should be removed.
•
of laser.
• Repairs of the laser may only be carried out by the
laser manufacturer or an authorised representa-
tive.
Residual risks
The electric tool has been built according to
state-of-the-art and the recognised technical
safety rules. However, individual residual risks
can arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
